Associated Numbers
A0599 UD15021A AS-PL AEK3658 AUTOELECTRO F000BL0803 BOSCHList F000BL0829 F000BL08P1 F000BL08P2 CAL10469 CASCO CAL10469AS CAL10469ES CAL10469GS CAL10469OS CAL10469RS CAL15552 CAL15552AS CAL15552ES CAL15552GS CAL15552OS CAL15552RS 9481 CEVAM DA2331 DELCO DRA1221 57424 EAI 28-6798 ELSTOCK ALB3903 KRAUF 553753RIV KUHNER 554038RIB 554268RIV LRA03658 LUCAS 89215744 POWERMAX 205.556.140 PSH 305.905.140 20101964 REAL 2010469 SANDO 2015552 439814 VALEO 440468 FG18T084 VALEOList TG14C041 TG14C096 TG14C104 06J903023A VW 06J903023AX 06J903023G VWList 06J903023GX 06J903023H 06J903023HX ALT10726 WOODAUTO ALT14576 VAL439814 VALTG14C041 ASPL 286798 12090486 EuroTec 205556140 Elstock 9090805F Friesen 931221 EDR Remy Bosch F000BL0803OR +line F000BLO803 06J903023B 20354 Lester 20354N WAI 2715993A Valeo 305905140 611730 715993 9090805 ALT0406sa Electrolog ALT1185sa Lucas TG14C041OR 06J903023D 06K903024A 113502 FARC 209493 Messmer LRA3658 show TG14C041SEL Volkswagen 12201356 AES Sando Wood Auto EVEAVE1225 Dapex F000BL08K1 F000BL08K2 F000BL08S9 F000BL08X5 RNLBL0803OER RNL RNLF000BL0803 WOOALT14576 F-000-BL0-803 F-000-BL0-829 F-00E-100-658 Reman AL0194X IAT A24226 Industry 24226 PIC 220-5837 11216 SEG Automotive F000.BL0.829 Group 06K903015AX Voltux V2-24226Specifications
| Amp | 140 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 9.5 mm |
| Diameter (D.3) | 8.5 mm |
| Diameter (D.4) | 9.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | Yes |
| Outside Diameter (O.D.1) | 56 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | Premium Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 28 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A1 1.8 TFSi | [DAJB] | 01.2015- |
| AUDI | A3 1.8 TFSi | [CJSA] | 01.2013- |
| AUDI | A3 1.8 TFSi | [CJSB] | 01.2013- |
| AUDI | A3 1.8 TFSi Quattro | [CJSA] | 01.2013- |
| AUDI | A3 1.8 TFSi Quattro | [CJSB] | 01.2013- |
| AUDI | A3 2.0 S3 Quattro | [CJXB] | 01.2012- |
| AUDI | A3 2.0 S3 Quattro | [CJXC] | 01.2012- |
| AUDI | Q3 2.0 TFSi | [CULB] | 01.2015- |
| AUDI | Q3 2.0 TFSi Quattro | [CULB] | 01.2014- |
| AUDI | S1 2.0 Quattro | [CWZA] | 01.2014- |
| AUDI | S3 2.0 Quattro | [CJXB] | 01.2012- |
| AUDI | S3 2.0 Quattro | [CJXC] | 01.2012- |
| AUDI | S3 2.0 Quattro | [CJXF] | 01.2012- |
| AUDI | TT 1.8 TFSi | [CJSA] | 01.2015- |
| AUDI | TT 2.0 TFSi | [CHHC] | 01.2014- |
| AUDI | TT 2.0 TFSi | [CJYF] | 01.2014- |
| AUDI | TT 2.0 TFSi | [CJYG] | 01.2014- |
| AUDI | TT 2.0 TFSi Quattro | [CHHC] | 01.2014- |
| AUDI | TT 2.0 TFSi Quattro | [CJYF] | 01.2014- |
| AUDI | TT 2.0 TFSi Quattro | [CJYG] | 01.2014- |
| SEAT | Alhambra 2.0 TSi | [DEDA] | 01.2015- |
| SEAT | Leon 2.0 Cupra | [CJXA] | 01.2013- |
| SEAT | Leon 2.0 Cupra | [CJXE] | 01.2013- |
| SKODA | Octavia 1.8 TSi | [CJSA] | 01.2012- |
| SKODA | Octavia 1.8 TSi | [CJSC] | 01.2012- |
| SKODA | Octavia 1.8 TSi 4x4 | [CJSA] | 01.2012- |
| SKODA | Octavia 1.8 TSi 4x4 | [CJSC] | 01.2012- |
| SKODA | Octavia 2.0 TSi RS | [CHHB] | 01.2013- |
| SKODA | Superb 1.8 TSi | [CJSA] | 01.2015- |
| SKODA | Superb 1.8 TSi | [CJSC] | 01.2015- |
| SKODA | Superb 2.0 TSi | [CHHB] | 01.2015- |
| SKODA | Superb 2.0 TSi 4x4 | [CJXA] | 01.2015- |
| VW | Golf VI 2.0 TSi | [CULC] | 01.2013- |
| VW | Golf VII 2.0 GTi | [CHHA] | 01.2013- |
| VW | Golf VII 2.0 GTi | [CHHB] | 01.2013- |
| VW | Golf VII 2.0 GTi | [CXDA] | 01.2013- |
| VW | Golf VII 2.0 R 4-Motion | [CJXB] | 01.2013- |
| VW | Golf VII 2.0 R 4-Motion | [CJXC] | 01.2013- |
| VW | Multivan 2.0 TDi | [CJKA] | 01.2015- |
| VW | Multivan 2.0 TDi | [CJKB] | 01.2015- |
| VW | New Beetle 2.0 TSi | [CULA] | 01.2014- |
| VW | New Beetle 2.0 TSi | [CULC] | 01.2014- |
| VW | Passat 1.8 TSi | [CJSA] | 01.2015- |
| VW | Passat 1.8 TSi | [CJSC] | 01.2015- |
| VW | Passat 2.0 TSi | [CHHB] | 01.2015- |
| VW | Passat 2.0 TSi | [CJXA] | 01.2015- |
| VW | Passat 2.0 TSi | [CXDA] | 01.2015- |
| VW | Passat 2.0 TSi 4-Motion | [CHHB] | 01.2015- |
| VW | Passat 2.0 TSi 4-Motion | [CJXA] | 01.2015- |
| VW | Passat 2.0 TSi 4-Motion | [CXDA] | 01.2015- |
| VW | Polo 1.8 GTi | [DAJA] | 01.2014-12.2016 |
| VW | Polo 1.8 GTi | [DAJB] | 01.2014-12.2016 |
| VW | Scirocco 2.0 TSi | [CULA] | 01.2013- |
| VW | Scirocco 2.0 TSi | [CULC] | 01.2013- |
| VW | Sharan 2.0 TSi | [DEDA] | 01.2015- |
| VW | Tiguan 2.0 TFSi 4-Motion | [CHHB] | 01.2016- |
| VW | Tiguan 2.0 TFSi 4-Motion | [CZPA] | 01.2016- |
| VW | Touran 1.8 TSi | [CJSA] | 01.2015-12.2017 |
| VW | Transporter 2.0 TSi | [CJKA] | 01.2015- |
| VW | Transporter 2.0 TSi | [CJKB] | 01.2015- |
Reference Information
89215744 AEK3658 209286 F000BL08S5 06K903024CX 553753RIB A12VA0863A2 442121 57424 06J903023GX 20101964OE CAL10469GS CAL15552GS 554038RIB 553753RIV PRAS643 24226N 8EL015630-031 ALTS643V 439814 2015552.1 20179255OE UD17456A 1986A01391 90-15-6712 UD15021A 06J903023G 06J903023H LRA3658 06J903023A 06J903023B 205.556.140.014 TG14C041 06J903023BX 06J903023D 2010469.1 205.556.140.019 ALB3903 ALT14576 F000BLO803 VALTG14C041 A0599S 06J903023AX ALT0406 F000BL0803 9481 A12VA0863 06K903024AX ALT175520 5515504 125812191 DRA1221 A12BH0754AS 32000322 06K903024C TG14C096 986086080 06K903024A 28-6798 ALTS643 LRA03658 124525593 440468 DA2331 205.556.140.282 A12VA0863AS VAL439814 F000BL08X5 F000BL08P2 205.556.140.281 F000BL08P1 F000BL08K1 F000BL08S9 06J903023HX F000BL0829 F000BL08K2 116387 06J903023DX ALT10726 1986A01251 1986A01373 TG14C104
