Associated Numbers
A0370 ASPL List UD13741A 0124655057 BOSCH 0124655102 0124655507 116098 CARGO CAL10656 CASCO CAL10667 DRA1419 DELCO 16055222 DIXIE 16055222R A6653 EAA222421 EAA ALB5557 KRAUF ALB5557NW ALB8557 816.505.150 PSH 816.508.150 21561402 RENAULT 7421561402 20988293 VOLVO 85009932 UNIT BOM 220684 WAI / TRANSPO 220690 BOS0124655057 WOODAUTO BOS0124655102 UD10870A 0124655499 0124655008 BXA4021 0986049360 114212 115488 CAL10624 CAL10624AS CAL10624GS 2474 CEVAM 19092000 30008VL DRB0002 DRB0002X 16055202 A6473 EAA222066 484993 ELSTOCK 210674 ERA AG0098 GHIBAUDI CA1883IR HC PARTS 8EL012584271 HELLA 8EL738211611 11.209.620 ISKRA LETRIKA AAN5409 IA9468 ALB1883 ALM1883 LRA02877 LUCAS LRA2877 063536550080 MAGNETI MARELLI MAN2032 MG802 MAHLE 89213744 POWERMAX 860804GB PRESTOLITE 816.501.110 20101426BN REAL 20101426OE 7420849351 7421429786 20409240 20849351 21429786 85000628 23877N ALT10303 BOS0124655008 ANB5009 860804 a0063 Renault Youtech/PartRef 325956 J N 40024048 Bosch 0124655012 0124655013 0124655019 0986048587 0986049350 AL5051X DAF 0910378 John Deere AT300167 AT387574 SE501838 Lester 12493 23876 23877 PIC Picture ID 2205290 2205295 2205298 Volvo 12734936 20466317 20849352 21429787 3803640 Wilson 90156467 12090746 EuroTec 816505150 816508150 ALT1335sa Electrolog KTR1633016300 KTR 0124655123 0124655279 506512150 5801543477 Iveco 931580 EDR DRA1580 Remy 160-55222 160-55222R 2010656 2010667 553693RI 553693RIB 861332 A-6653 CAL10656AS CAL10656ES CAL10656GS CAL10656OS CAL10656RS CAL10667AS CAL10667ES CAL10667GS CAL10667OS CAL10667RS EAA-222421 220-684 220-690
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 13.5 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 12.5 mm |
| Diameter (D.3) | 12.5 mm |
| Grooves | 8 qty |
| Length (L.1) | 221 mm |
| Mount Inside Length or Pad Mount C-C (C) | 102.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 63 mm |
| Plug Code | PL_5003 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 45.5 mm |
| Pulley Type | SOLID |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VOLVO | B9 9.3 | [D9B260] | 09.2005- |
| VOLVO | B9 9.3 | [D9B310] | 09.2005- |
| VOLVO | B9 9.3 | [D9B360] | 09.2005- |
| VOLVO | B9 9.3 | [G9A260] | 09.2005- |
| VOLVO | FH 16/540 16.1 | [D16E540] | 01.2009- |
| VOLVO | FH 16/540 16.1 | [D16G540] | 01.2009- |
| VOLVO | FH 16/540 16.1 | [D16G540] | 08.2007- |
| VOLVO | FH 16/550 16.1 | [D16C550] | 01.2003- |
| VOLVO | FH 16/550 16.1 | [D16C550] | 05.2005- |
| VOLVO | FH 16/550 16.1 | [D16C550] | 08.2007- |
| VOLVO | FH 550 16.1 | [D16C550] | 09.2005- |
