Associated Numbers
BBB Industries 52077
Bosch 0-001-149-420, 0-001-149-421, 0-001-149-434, 0-001-149-435
Bosch Reman SR6535X
Chrysler 5602 9667AB, 56029667AA, 56029667AB
IAT S424102
Industry 16427
Lester 16427
PIC 120-913
SEG Automotive 0001.149.434
Standard Starter Drive 424102
Voltux V1-16427
Wilson 91-15-7342
Bosch 0-001-149-420, 0-001-149-421, 0-001-149-434, 0-001-149-435
Bosch Reman SR6535X
Chrysler 5602 9667AB, 56029667AA, 56029667AB
IAT S424102
Lester 16427
PIC 120-913
SEG Automotive 0001.149.434
bsx0189
Specifications
| Kilowatt | 21.8 kW |
| Length (L.1) | 245 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | 10 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 12 qty |
| Pinion at Rest (B) | 21 mm |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
