S5016SR - Remanufactured AS-PL Starter motor

Name: Remanufactured AS-PL Starter motor
Brand: AS GROUP NZ
SKU: S5016SR
Price: 222.01 NZD
Availability: OutOfStock

Remanufactured AS-PL Starter motor

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

MITSUBISHI

Price:

NZ$ 222.01 including GST

NZ$ 193.05 excluding GST

UOM:

each

Product Code:

S5016SR

Quantity In Stock Nationally:

No stock in NZ

Availability:

No stock in NZ

Specifications
Vehicle Applications
Reference Information
Add Your Number

Kilowatt	0.7 kW
Length (L.1)	189 mm
Mount Hole Center - Center (O.1)	105 mm
Mount Hole Diameter (C.1)	9.5 mm
Mount Hole Diameter (C.2)	9.5 mm
No./Mount holes	2 qty
No./Mount holes with thread	0 qty
No./Teeth	8 qty
No./Teeth (Replaces)	8. 9 qty
Pinion at Rest (B)	4.5 mm
Rotation	CW
Spigot Diameter (A)	66 mm
Unit Type	MITSUBISHI
Voltage	12 V

Make	Model	Type	Year
SUZUKI	Grand Vitara 1.6	[G16B]	03.1998-
SUZUKI	Jimny 1.3 16V	[G13BB]	09.1998-
SUZUKI	Jimny 1.3 16V	[M13A]	02.2001-
SUZUKI	Jimny 1.3 16V 4WD	[G13BB]	09.1998-
SUZUKI	Jimny 1.3 16V 4WD	[M13A]	02.2001-
SUZUKI	Samurai 1.3	[G13A]	11.1988-
SUZUKI	Samurai 1.3	[G13BA]	11.1988-
SUZUKI	SJ 413 1.3	[G13A]	08.1984-08.1990
SUZUKI	Vitara 1.6	[G16A]	09.1988-03.1998
SUZUKI	Vitara 1.6 16V	[G16B]	09.1991-12.1994
SUZUKI	Vitara 1.6 i 4WD	[G16B]	07.1990-03.1999
SUZUKI	X-90 1.6 i 16V	[G16B]	09.1995-
SUZUKI	X-90 1.6 i 16V 4WD	[G16B]	09.1995-

M001T74583ZC 9.43252E+11 M003T41781 STM0380 31100-83021 PRSL019 31100-83020 31100-83421 31100-60AD0 20437101BN 110394 M1T72481ZC 455901 M3T34782B 25-1261 M3T39981 31100-60AC2 J5218017 31100-83030 31100-83031 ANM15265X 20500605 0001112032 31100-60A22 9747 31100-60A20 M003T34782-B 31100-60A10-000 M1T74583ZC M3T38981 SS253 31100-60AB1 EAA-121037 31100-60AB2 M001T74581 220017 M001T74583 31100-60AB0 986014350 986014351 M003T24782 LRS605 3110082021 11562 31100-60A10 31100-60A11 31100-60A12 31100-60A13 M001T72483ZC M003T31471 1A51-18-400 3110093031 M1T72481 3110083010L M1T72483 3110085C00 436053 M3T34782 31100-60A12-000 M3T34781 3110060AD0 M3T38982 3110060A20000 3.11008E+12 M003T39981 CST35101AS M3T34782-B M001T74581ZC 22.538 SS839 STR5059 96064782 20380M 31100-A83031 STR71031 M003T38981 M1T72483ZC CGB-51261 M003T34781 M003T34782 3110060A22 3110060A20 M0T85781 31100-82021 S12MH0042A2 SS389 31100-60A20-000 RNL213ZS 3110083021 6035101 20380 JS380 LRS00605 22.5380M STRL019 3110-60AB1 8052805 M1T74581ZC 180.004.082.415 3110060A13 3110060A12 31106-0AB1 3110060A11 3110060A10000 429917400 M001T72481 MQS0380 M001T72483 1112032 M000T85781 M001T72481ZC 000986014350 31100-A83010 000986014351 96058456 180.004.082.130 M1T74583 M1T74581 M3T41781 31100-83010 31100-83011 M3T24782 16966N 8EA011611-141 3100083021 335230 MAV6160 M3T31471 31100-85C00
