Specifications
| Kilowatt | 0.8 kW |
| Length (L.1) | 207 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 53 mm |
| Mount Hole Center - Center (O.3) | 67 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 13 mm |
| Rotation | CW |
| Spigot Diameter (A) | 62 mm |
| Unit Type | LUCAS/MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUTOBIANCHI | A 112 0.9 | [A112A5.000] | 01.1976-12.1978 |
| AUTOBIANCHI | A 112 0.9 | [A112A5.000] | 10.1969-12.1972 |
| AUTOBIANCHI | A 112 0.9 E | [A112A5.000] | 01.1973-12.1977 |
| AUTOBIANCHI | A 112 0.9 Junior | [A112A5.000] | 07.1975-12.1985 |
| AUTOBIANCHI | A 112 0.9 Junior | [A112B2.000] | 07.1975-12.1985 |
| AUTOBIANCHI | A 112 1.0 Abarth | [A112A1.000] | 09.1971-12.1975 |
| AUTOBIANCHI | A 112 1.0 Abarth | [A112A2.000] | 01.1974-12.1984 |
| AUTOBIANCHI | A 112 1.0 E | [A112B1.000] | 11.1977-12.1985 |
| AUTOBIANCHI | A 112 1.0 Elite | [A112B1.000] | 11.1977-12.1985 |
| AUTOBIANCHI | A 112 1.0 LX | [A112B1.000] | 11.1977-12.1985 |
| FIAT | 127 0.9 | [100GL.000] | 09.1971-12.1984 |
| FIAT | 127 0.9 | [100GL.048] | 06.1971-05.1983 |
| FIAT | 127P 0.9 | [100GL.000] | 10.1969-10.1976 |
| FIAT | 600 0.9 | [1170A1.046] | 01.1998-01.2010 |
| FIAT | 600 0.9 | [1170A1.046] | 11.1997-12.2008 |
| FIAT | Cinquecento 0.9 | [170A1.000] | 07.1991-12.1993 |
| FIAT | Cinquecento 0.9 i.e. | [170A1.046] | 07.1991-09.1994 |
| FIAT | Cinquecento 0.9 i.e. S | [1170A1.000] | 07.1991-07.1999 |
| FIAT | Cinquecento 0.9 i.e. S | [1170A1.046] | 07.1991-07.1999 |
| FIAT | Fiorino 900 | [100GL.000] | 10.1977-10.1986 |
| FIAT | Panda 1000 | [156A3.000] | 01.1985-12.1992 |
| FIAT | Panda 750 | [141B.000] | 01.1986-07.1992 |
| FIAT | Panda 750 | [156A4.000] | 01.1986-10.2003 |
| FIAT | Panda 750 | 01.1986-01.1995 | |
| FIAT | Panda 750 Cat | 01.1995-10.2003 | |
| FIAT | Panda 800 | [100GL6.000] | 02.1981-12.1985 |
| FIAT | Panda 900 | [100GL3.000] | 10.1980-06.1994 |
| FIAT | Panda 900 | [1170A1.046] | 04.1992-12.1996 |
| FIAT | Panda 900 | [146A.000] | 10.1980-06.1994 |
| FIAT | Panda 950 4x4 | [A112B1.054] | 09.1983-12.1986 |
| FIAT | Seicento 0.9 | [1170A1.046] | 01.1998-01.2010 |
| FIAT | Seicento 0.9 | [1170A1.046] | 11.1997-12.2008 |
| FIAT | Uno 45 0.9 | [146A.000] | 03.1983-09.1992 |
| FIAT | Uno 45 0.9 | [146A1.000] | 03.1983-09.1992 |
| FIAT | Uno 45 i.e. 1.0 | [156A2.246] | 04.1984-10.1995 |
| INNOCENTI | Koral 45 | [100GL.064] | 01.1990-12.1992 |
| LANCIA | A 112 0.9 Junior | [A112A.000] | 03.1981-06.1986 |
| LANCIA | A 112 0.9 Junior | [A112A5.000] | 03.1981-06.1986 |
| LANCIA | A 112 0.9 Junior | [A112B2.000] | 03.1981-06.1986 |
| LANCIA | A 112 1.0 LX | [A112B1.000] | 03.1984-12.1986 |
| SEAT | 127 0.9 | [A112A5.000] | 04.1972-12.1982 |
| SEAT | Fura 0.9 | [09NCA] | 03.1984-12.1986 |
| SEAT | Fura 0.9 | [100GL3000] | 01.1982-06.1986 |
| SEAT | Fura 0.9 | [100GL7000] | 03.1984-12.1986 |
| SEAT | Fura 0.9 | [HB90] | 01.1982-06.1986 |
| SEAT | Ibiza 0.9 | [09NCA] | 08.1990-05.1993 |
| SEAT | Ibiza 0.9 | [146A000] | 08.1986-05.1993 |
| SEAT | Ibiza 0.9 | [146A000] | 08.1990-05.1993 |
| SEAT | Ibiza 1.2 | [021A1000] | 11.1984-12.1993 |
| SEAT | Ibiza 1.2 i | [021C.1000] | 01.1989-05.1993 |
| SEAT | Ibiza 1.5 | [021A2000] | 11.1984-05.1993 |
| SEAT | Ibiza 1.5 i | [021B.2000] | 10.1986-05.1993 |
| SEAT | Ibiza 1.5 i Cat | [021C.2000] | 10.1986-05.1993 |
| SEAT | Malaga 1.2 | [021A1000] | 05.1985-12.1993 |
| SEAT | Malaga 1.5 | [021A2000] | 05.1985-12.1993 |
| SEAT | Malaga 1.5 i | [021B.2000] | 01.1987-12.1993 |
| SEAT | Malaga 1.5 i Cat | [021A2000] | 10.1986-12.1993 |
| SEAT | Malaga 1.5 i Cat | [021C.2000] | 10.1986-12.1993 |
| SEAT | Malaga 1.5 i Cat | [021D.2000] | 10.1986-12.1993 |
| SEAT | Marbella 0.8 | [08NCA] | 01.1987-12.1993 |
| SEAT | Marbella 0.8 | [08NCA] | 08.1986-12.1993 |
| SEAT | Marbella 0.9 | [09NCA] | 01.1987-12.1993 |
| SEAT | Marbella 0.9 | [100GL7000] | 01.1987-12.1993 |
| SEAT | Marbella 0.9 Cat | [08NCB] | 11.1996-10.1998 |
| SEAT | Marbella 0.9 Cat | [09NCB] | 01.1987-12.1993 |
| SEAT | Marbella 0.9 Cat | [09NCB] | 01.1990-11.1996 |
| SEAT | Marbella 0.9 Cat | [100GL7000] | 01.1990-11.1996 |
| SEAT | Panda 0.9 | [100GL3000] | 10.1980-12.1986 |
| SEAT | Ronda 1.2 | [021A1000] | 10.1984-12.1986 |
| SEAT | Ronda 1.2 | [124B6.000] | 08.1983-05.1985 |
| SEAT | Ronda 1.5 | [021A2000] | 09.1984-12.1986 |
| SEAT | Ronda 1.6 | [022A000] | 08.1983-09.1985 |
| SEAT | Ronda 1.6 | [138AR6.000] | 08.1983-09.1985 |
| SEAT | Ronda 1.7 D | [022A.5000] | 06.1982-12.1986 |
| SEAT | Terra 0.9 | [09NCA] | 01.1987-12.1995 |
| SEAT | Terra 0.9 Cat | [09NCB] | 02.1992-12.1994 |
Reference Information
30191R 3914191 PRSL138 7737262 20404311BN 3974104 GS222905M-R 8EA737273-001 STE1038 CS90 20404311OE 46406970 S12MA0055A2 SS222905-A 220162A SE21908000A 500.515.093.265 MAHMS382 71782312 3915113 111585 63222897 71782314 4401806 46465273 71782313 8EA012526-811 CST30113RS HB90800004 5030230 4468806 HB90800002 220162R SE21908000 335650 71721244 71721245 SG0141 20404311EL STRL138 20404311RE MAV1030A 101038 CST30113ES 77201430 20404311RC LRS234 STR52020 46797350 CST30113AS 500.013.093.058 6030113 110365 CST30113GS 42001222 500.013.093.050 CS1038 63222908 DSN585 CST30113OS 63222905 DRS7041X LRS00234 6030113.4 6030113.3 25-2257 77175430 6030113.2 7668988 IS0586 DRS7041 DRS7041N STR9076 4229114 5972684 4229113 XO39741040 63222837 GS222905-A 63222836 SS222905M-R 1090 46231500 943222836 500.013.093.265 DENDSN585 6030113.1 STR00295 46231505 46432301 CGB-52257 46231504 XO39466650 88212700 STR52001Add Your Number
