S4030SR - Remanufactured AS-PL Starter motor

Name: Remanufactured AS-PL Starter motor
Brand: AS GROUP NZ
SKU: S4030SR
Price: 444.02 NZD
Availability: InStock

Remanufactured AS-PL Starter motor

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

MAGNETI MARELLI

Price:

NZ$ 444.02 including GST

NZ$ 386.10 excluding GST

UOM:

each

Product Code:

S4030SR

Quantity In Stock Nationally:

No stock in NZ

Availability:

Item available to backorder, submit your order. Aprox 7-14 day delay - $40 Air freight charge additional

Specifications
Vehicle Applications
Reference Information
Add Your Number

Kilowatt	3 kW
Length (L.1)	292 mm
Mount Hole Center - Center (O.1)	127 mm
Mount Hole Center - Center (O.2)	90 mm
Mount Hole Center - Center (O.3)	90 mm
Mount Hole Diameter (C.1)	11.5 mm
Mount Hole Diameter (C.2)	11.5 mm
Mount Hole Diameter (C.3)	11.5 mm
No./Mount holes	3 qty
No./Mount holes with thread	0 qty
No./Teeth	10 qty
Pinion at Rest (B)	30.5 mm
Rotation	CW
Spigot Diameter (A)	89 mm
Unit Type	LUCAS/MARELLI
Voltage	12 V

Make	Model	Type	Year
JCB	526S 4.4	[1104C-44R]	01.1997-
KIOTI	DK65 2.7	[903.27T]	01.2002-01.2007
KIOTI	DK65C 2.7	[903.27T]	01.2002-01.2007
KIOTI	DK90 4.4	[1104D-44T]	01.2007-
PERKINS	1103D-33		01.2004-

CST21108AS 113655 700.504.103.265 E7100-63012 CST30170AS 63280041010 MAV231080 AEX1050 6030170 CGB-93405 CST30170IS 2873K405 91-19-2515 MSN8041 63280041 71440231 9.44288E+11 25-4097 3786310M1 220702 EAA-121063 700.504.103.311 71440536 6021108.1 E730163011 STE3655 190-80101 AZE4173 254193K 2873K634 254193L 254193M 6021108 20404071IT IS1201 2872K405 LRS02425 MAV321700 CST30170GS CST21108GS 20419801BN 2873K624 428000-1290 MS399 M1T84181 254193 2873K626 26.0005 20404071BN 2873K625 SG0133 RNL2873K405 PRSS023 20419801OE 700.504.103.208 71440531 STR52055 4227054M91 6030170.5 LRS2425 8719R 074000-0000 700.504.103.098 714/40231 20404071OE STRS023 700.504.103.050 STR9009 6030170.1 72736027 18940N 700.504.103.090 35263300 7169477 MRS18320 860715 26.0005M 11.131.781 88213712 STR70057
