Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 236 mm |
| Mount Hole Center - Center (O.1) | 83 mm |
| Mount Hole Center - Center (O.2) | 116 mm |
| Mount Hole Center - Center (O.3) | 83 mm |
| Mount Hole Diameter (C.1) | 8.5 mm |
| Mount Hole Diameter (C.2) | 8.5 mm |
| Mount Hole Diameter (C.3) | 8.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 9 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | 145 1.9 JTD | [AR32302] | 02.1999-01.2001 |
| ALFA ROMEO | 147 1.9 JTD | [937A2.000] | 11.2000-05.2002 |
| ALFA ROMEO | 147 1.9 JTD 16V | [192A5.000] | 04.2005- |
| ALFA ROMEO | 147 1.9 JTD 16V | [937A4.000] | 04.2005- |
| ALFA ROMEO | 147 1.9 JTDM | [937A6.000] | 06.2008- |
| ALFA ROMEO | 147 1.9 JTDM 16V | [937A5.000] | 07.2005- |
| ALFA ROMEO | 156 1.9 JTD | [937A2.000] | 05.2001-05.2006 |
| ALFA ROMEO | 156 1.9 JTD | [AR32302] | 09.1997-10.2000 |
| ALFA ROMEO | 156 1.9 JTD | [AR37101] | 10.2000-12.2001 |
| ALFA ROMEO | 159 1.9 JTDM 16V | [937A8.000] | 09.2005- |
| ALFA ROMEO | 159 1.9 JTDM 16V | [939A2.000] | 09.2005- |
| ALFA ROMEO | 159 1.9 JTDM 16V | [939A8.000] | 09.2005- |
| ALFA ROMEO | 159 1.9 JTDM 8V | [939A7.000] | 09.2005- |
| FIAT | Brava 1.9 JTD | [182B4.000] | 12.1998-10.2001 |
| FIAT | Brava 1.9 JTD | [182B9.000] | 09.2000-10.2001 |
| FIAT | Brava 1.9 TD | [182A7.000] | 03.1996-10.2001 |
| FIAT | Brava 1.9 TD | [182A8.000] | 03.1996-10.2001 |
| FIAT | Bravo 1.6 Multijet | [198A2.000] | 03.2008- |
| FIAT | Bravo 1.9 Diesel Multijet | [937A5.000] | 04.2007- |
| FIAT | Bravo 1.9 JTD | [182B4.000] | 12.1998-10.2001 |
| FIAT | Bravo 1.9 JTD | [182B9.000] | 09.2000-10.2001 |
| FIAT | Bravo 1.9 TD | [182A7.000] | 03.1996-10.2001 |
| FIAT | Croma 1.9 Diesel Multijet | [939A2.000] | 06.2005- |
| FIAT | Doblo 1.9 JTD | [182B9.000] | 10.2001- |
| FIAT | Doblo 1.9 JTD | [223A7.000] | 10.2001-09.2005 |
| FIAT | Doblo 1.9 JTD | [223B1.000] | 10.2001-09.2005 |
| FIAT | Doblo 1.9 JTD | [223B2.000] | 10.2001- |
| FIAT | Grande Punto 1.9 Diesel Multijet | [199A5.000] | 10.2005- |
| FIAT | Marea 1.9 JTD | [182B4.000] | 04.1999-01.2001 |
| FIAT | Marea 1.9 JTD | [186A6.000] | 01.2001- |
| FIAT | Marea 1.9 TD | [182A7.000] | 09.1996- |
| FIAT | Marea 1.9 TD | [182A8.000] | 09.1996- |
| FIAT | Marea 1.9 TDi | [182A7.000] | 09.1996- |
| FIAT | Marengo 1.9 JTD | [182B4.000] | 03.1999-09.2002 |
| FIAT | Marengo 1.9 JTD | [186A6.000] | 08.2000-09.2002 |
| FIAT | Marengo 1.9 TD | [182A7.000] | 01.1997-02.1999 |
| FIAT | Marengo 1.9 TD | [182A8.000] | 03.1999-09.2002 |
| FIAT | Multipla 1.9 JTD | [182B4.000] | 04.1999- |
| FIAT | Multipla 1.9 JTD | [186A6.000] | 03.2001- |
| FIAT | Multipla 1.9 JTD | [186A8.000] | 07.2002- |
| FIAT | Punto 1.9 JTD | [188A2.000] | 09.1999- |
| FIAT | Punto 1.9 JTD | [188A7.000] | 06.2001-06.2003 |
| FIAT | Stilo 1.9 Diesel | [192B5.000] | 09.2004- |
| FIAT | Stilo 1.9 Diesel Multijet | [192A8.000] | 09.2005- |
| FIAT | Stilo 1.9 Diesel Multijet | [192A9.000] | 09.2005- |
| FIAT | Stilo 1.9 Diesel Multijet | [937A5.000] | 09.2005- |
| FIAT | Stilo 1.9 JTD | [192A1.000] | 10.2001- |
| FIAT | Stilo 1.9 JTD | [192A3.000] | 10.2001- |
| FIAT | Stilo 1.9 JTD | [192B5.000] | 09.2004- |
| FIAT | Stilo 1.9 JTD | [937A7.000] | 01.2003- |
| FIAT | Strada 1.9 JTD | [188A2.000] | 04.2003- |
| LANCIA | Lybra 1.9 JTD | [937A2.000] | 05.2001- |
| LANCIA | Lybra 1.9 JTD | [AR32302] | 07.1999-09.2000 |
| LANCIA | Lybra 1.9 JTD | [AR37101] | 09.2000- |
| LANCIA | Lybra 1.9 JTD SW | [AR37101] | 09.2000- |
| LANCIA | Lybra 2.4 JTD | [839A5.000] | 10.1999-09.2000 |
| LANCIA | Lybra 2.4 JTD | [839A6.000] | 09.2000-05.2002 |
| LANCIA | Lybra 2.4 JTD | [AR32501] | 10.1999-09.2000 |
| LANCIA | Lybra 2.4 JTD SW | [839A6.000] | 09.2000-05.2002 |
| LANCIA | Thesis 2.4 JTD | [841C.000] | 04.2002- |
Reference Information
500.579.093.215 63113002010 6010287.1 MRS18900 31100-H79J0-0000 PRSS207 6202074 CST10287OS 201162 0001109253 51832954 51832953 CST10287GS 60814911 63521082390 71721774 71722349 CGB-53002 AZE2111 101045 20401492BN 71789267 31100-79J00 46748351 42018900 IS0997 0001115025 32669N 71721240 20404111OE 0001115021 500.579.093.210 0001109268 0001109269 6030111 000986017790 GS109030B-R 60817002 31100H79J00-000 S12BH0020A2 31100-79J00-000 46473784 201068 311348 46522234 STRL008B 9.4321E+11 458212 8EA737294-001 STRL008 20401782RE 1109336 101045B 1109337 55585237 20510199 55195211 6030111.2 6030111.1 63721045010 DENDSN3018 46478945 101045M CST10294OS 46437520 331197 63114008010 93951832953 20401782BN CST10294GS MSN610 71746669 458585 ANM15534X 3110079J00000 3680 1109045 500.579.093.018 220155 MS373 51782321 46451895 20404111RC 25-3002 6010294 458550 LRT199 55353857 STM1035 0001109336 STM1278 0001109337 726043 CST10287AS MSRC1045 88212453 46463250 55192482 93955195029 20401492OE 8EA011610-011 72736001 1109030 31202N 46430784 551952110 CST30111RS STR1945 1109270 9.4428E+11 MQS1045 STRS207 71723345 71794169 46835091 71723462 20404111BN CST30111AS S12BH0789A2 113297 500.579.093.770 CST10294AS 1109438 500.579.093.010 46817002 1109269 71782384 20401492RE 71782386 1109268 CST30111GS DRS3314X 46800159 55195029 1115021 0001109270 STB1045 0001109030 1115025 SG0099 71742375 11.130.997 71792037 GS109030-A 0001109438 46830212 20401782OE 63521092680 6010294.4 4765911 71782379 46823543 LRT00199 MAV122940 PRSL008 1109253 6010294.1 9.43114E+11 220720 986017790 RAS34425 60816083 11932 MRS17790 MSR610 1202282 STR52046 0001109045 113430 63113002 63721264010 6010287 STR79103 55832954Add Your Number
