Specifications
Kilowatt | 4 kW |
Length (L.1) | 341 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 28 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
IVECO | MK 110-13 6.1 | [BF6L913T][F6L913] | 04.1985-02.1986 |
IVECO | MK 110-16 6.1 | [BF6L913T][F6L913] | 03.1986-12.1991 |
IVECO | MK 130-13 6.1 | [BF6L913T][F6L913] | 03.1986-05.1989 |
IVECO | MK 130-16 6.1 | [BF6L913] | 03.1986-12.1991 |
IVECO | MK 75-9 4.1 | [BF4L913T] | 11.1985-05.1989 |
IVECO | MK 80-13 6.1 | [BF6L913T][F6L913] | 03.1986-12.1989 |
IVECO | MK 80-16 6.1 | [BF6L913] | 03.1986-12.1989 |
IVECO | MK 90-13 6.1 | [BF6L913T] | 03.1986-12.1991 |
IVECO | P/PA 120-13 6.2 | [BF6L913T] | 08.1983-09.1990 |
IVECO | P/PA 120-13 6.2 | [F6L913] | 01.1983-02.1986 |
Reference Information
42522653 STR79045 6209190 11580 1161422 8EA012586-441 PRSF231 EAA-121337 E0041565 330682 881669 42368001 STB0530 1302023 10530 20401116EL B17R24X4 1231028 1360035 6010611 42522641 8660 88212370 10460 ANM13490 6200662 B7R24X4H7622 744648 11.130.491 TS-6018 CST10611AS 42498135 45-0219 511.001.093.311 E41565EX CS530 CST10611ES 1164995 1173820 1172099 LRS00923 0001231028 0001360012 110523 STR7934 72736014 1701065 6010611.3 17073N SG0056 260-67200 5710903 LRS923 22222006 1180999 1360012 AZJ3132 42522942 0001360003 STM1014 STR1070 STR7828 1182235 0001368001 1368001 3046537 MS386 1183243 STR7901 511.001.093.016 1516768R 20401116BN B29R24X4H7622 6107017 1170053 IS0491 0001360035 1115490 1173241 1173560 1180804 42488477 1360003 511.001.093.010Add Your Number
