Remanufactured AS-PL Alternator
STANDARD LINE
AS-PL
HYUNDAI / KIA
Price:
NZ$ 486.52 including GST
NZ$ 423.06 excluding GST
or four payments of $121.63
with
Learn More
UOM:
each
Product Code:
A9070SR
Quantity In Stock Nationally
No stock in NZ currently
No stock in NZ currently
Specifications
| Amp | 60 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 246 mm |
| Mount Inside Length or Pad Mount C-C (C) | 80.50 mm |
| OEM Product | No |
| Plug Code | PL_2505 |
| Product Line | Standard Line |
| Product Type | Remanufactured |
| Pulley Grooves | 2 qty |
| Pulley Groove Width (W.1) | 9 mm |
| Pulley Outside Diameter (O.D.1) | 71.50 mm |
| Pulley Outside Diameter (O.D.2) | 46 mm |
| Pulley to Mount Distance (A) | 47 mm |
| Pulley Type | Solid |
| Unit Type | HYUNDAI / KIA |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KIA | Retona 2.0 TD | 06.1999- | |
| KIA | RETONA Closed Off-Road Vehicle (FK) 2.0 TD | RF | 06.1999-12.2001 |
| KIA | Sportage 2.0 TD 4WD | [RF] | 10.1997-08.2003 |
| KIA | Sportage 2.2 4WD | 08.1994-04.1999 | |
| KIA | SPORTAGE SUV (K00) 2.0 TD 4WD | RF | 10.1997-08.2003 |
| KIA | SPORTAGE SUV (K00) 2.2 D 4WD | OK016 | 08.1994-04.1999 |
Reference Information
| 002-M951-2 | ASHIKA |
| 02121-8025 | POONGSUNG |
| 02121-8026 | POONGSUNG |
| 02121-8027 | POONGSUNG |
| 02121-8070 | POONGSUNG |
| 02121-8071 | POONGSUNG |
| 02121-8072 | POONGSUNG |
| 02121-8073 | POONGSUNG |
| 02121-8074 | POONGSUNG |
| 0K054-18300 | HYUNDAI / KIA |
| 0K054-18300A | HYUNDAI / KIA |
| 0K054-18300B | HYUNDAI / KIA |
| 0K054-18300C | HYUNDAI / KIA |
| 0K640-18300G | HYUNDAI / KIA |
| 0K740-18300G | HYUNDAI / KIA |
| 0K740-18300H | HYUNDAI / KIA |
| 112506 | CARGO |
| 20128001BN | REAL |
| 20128001OE | REAL |
| 20128001RE | REAL |
| 20130163 | PRESTOLITE |
| 2041100.0 | SANDO |
| 2041100.1 | SANDO |
| 2041100.4 | SANDO |
| 210250 | ERA |
| 255.801.060.008 | WAI |
| 255.801.060.120 | WAI |
| 255.801.060.138 | WAI |
| 255.801.060.260 | WAI |
| 255.801.060.360 | WAI |
| 255.801.060.366 | WAI |
| 255.801.060.415 | WAI |
| 28-4821 | ELSTOCK |
| 2M9512 | JAPKO |
| 37300-2W000 | HYUNDAI / KIA |
| 37300-2W001 | HYUNDAI / KIA |
| 401795RI | KUHNER |
| 401795RIM | KUHNER |
| 56957 | EAI |
| 89215757 | POWERMAX |
| 8EL012426-321 | HELLA |
| 9215757 | POWERMAX |
| 9411 | CEVAM |
| A132.333 | WAI |
| A147.303 | WAI |
| A149.672 | WAI |
| ALM951-2 | JAPANPARTS |
| ALT7410 | SIOM |
| ALT8793 | ELECTROLOG |
| ALTL277 | 3EFFE |
| ANM36418X | ANDEL |
| CAL41100AS | CASCO |
| CAL41100GS | CASCO |
| CAL41100OS | CASCO |
| CGB-14199 | AINDE |
| DRA4198 | DELCO |
| F032112506 | CARGO |
| JA1795IR | HC PARTS |
| LRA02326 | LUCAS |
| LRA2326 | LUCAS |
| OK054-18300 | HYUNDAI / KIA |
| OK054-18300A | HYUNDAI / KIA |
| OK054-18300B | HYUNDAI / KIA |
| OK054-18300C | HYUNDAI / KIA |
| OK640-18300G | HYUNDAI / KIA |
| OK740-18300 | HYUNDAI / KIA |
| OK740-18300E | HYUNDAI / KIA |
| OK740-18300F | HYUNDAI / KIA |
| OK740-18300G | HYUNDAI / KIA |
| OK740-18300H | HYUNDAI / KIA |
| PRAL277 | 3EFFE |
| STX100467 | STARDAX |
