Specifications
Kilowatt | 9 kW |
Length (L.1) | 410 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | ISC Series 8.3 | 01.2003-12.2013 | |
JCB | 446 8.3 | [6CTAA] | 01.1997-12.2001 |
JCB | 456 8.3 | [6CTAA] | 01.1996-12.2002 |
KOMATSU | PC300HD-6 8.3 | [SA6D114E] | 01.1998-12.2001 |
KOMATSU | PC300HD-6LC 8.3 | [SA6D114E] | 01.1995-12.1999 |
KOMATSU | PC300HD-6LE 8.3 | [SA6D114E] | 01.1999-12.2001 |
KOMATSU | PC300HD-6MH 8.3 | [SA6D114E] | 01.1995-12.1999 |
KOMATSU | PC300LC-6LC 8.3 | [SA6D114E] | 01.1995-12.1999 |
KOMATSU | PC300LC-6LE 8.3 | [SA6D114E] | 01.1999-12.2001 |
KOMATSU | PC300LL-6 8.3 | [SA6D114E] | 01.2003-12.2004 |
Reference Information
19011524 19011511 CGB-1748 0-61000-0380 5173108 3102767 3675296RX 91-01-4572 91-01-4572N UD100825(NIKKO)S 3675297RX STD4013 114013 8200029 641.010.123.710 REM19011524 10461758 10461759 8200086Add Your Number
