Specifications
Kilowatt | 7.3 kW |
Length (L.1) | 498 mm |
Mount Hole Center - Center (O.1) | 103 mm |
Mount Hole Center - Center (O.2) | 147 mm |
Mount Hole Center - Center (O.3) | 103 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 46 mm |
Rotation | ACW |
Spigot Diameter (A) | 92 mm |
Unit Type | NIKKO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | Various Models |
Reference Information
2071535 0-61000-0420 9192004400 2071533 640.051.123.710 1046547 10478968 255063 10R0403 6060116.1 1716596 10461325 4N9801 1990365 1939185 10478971 10479007 UD100829(NIKKO)S 416518 20409611OE CST60116AS 10478816 12R0403 8C3646 6060116 20409611BN CST60116GS 3142307 10461037 1045725 1045724Add Your Number
