Specifications
Kilowatt | 3.5 kW |
Length (L.1) | 340 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | Various Models |
Reference Information
641.527.103.710 0-61000-0050 STR80117 1113277 3918378 20446356OE 707112 6050653.1 3604677RX 1113291 CST50653GS UD100802(NIKKO)S 91-01-4361N 9011707112 STD0857Add Your Number
