Specifications
Kilowatt | 2.5 kW |
Length (L.1) | 305 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Center - Center (O.2) | 79 mm |
Mount Hole Center - Center (O.3) | 84.8 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 14.2 mm |
Rotation | CW |
Spigot Diameter (A) | 90 mm |
Unit Type | NIKKO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | Engine 5.2 | [4HK1] | |
ISUZU | Engine 5.2 | [4HK1T] |
Reference Information
0-24000-0198 0-61000-0310 8980636991 UD100780(NIKKO)SAdd Your Number
