Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 292 mm |
Mount Hole Center - Center (O.1) | 111 mm |
Mount Hole Center - Center (O.2) | 136 mm |
Mount Hole Center - Center (O.3) | 111 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
Mount Hole Diameter (C.3) | 13 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 40.5 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 225C | [6BG1T] | 01.1999- |
Reference Information
8983763930 185-24011 1811003380 254572 131.515.113.710 220633 6050622.1 1811003310 91-28-4069 254572K UD100778(NIKKO)S UD100715(NIKKO)S 19868 20446226BN STR8819 0-61000-0250 19868N CST50622AS 0-24000-3151 0-24000-3150 CST50622GS 131.515.113.170 S24NK0029A2 246-25227 1811003381 114267 6050622 STK4267 20446226OEAdd Your Number
