Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 200 mm |
Mount Hole Center - Center (O.1) | 80 mm |
Mount Hole Center - Center (O.2) | 20 mm |
Mount Hole Center - Center (O.3) | 137 mm |
Mount Hole Center - Center (O.4) | 77 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
Mount Hole Diameter (C.4) | M10x1.5 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 4 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 20 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Juke 1.6 | [HR16DE] | 01.2013- |
NISSAN | Juke 1.6 CVTC | [HR16DE] | 08.2014- |
NISSAN | Qashqai 1.6 LPG | [HR16DE] | 11.2010-12.2013 |
Reference Information
UD100047(MITSUBISHI)S M000T37971AM M0T37971AM M0T37971ZE M000T37971ZE M000T32177 M000T37971 25-4376 116253 23300-BB00A 23300-BB00B 458930 STM1795 88214756 CST35329GS M0T32177 9613 LRS2704 20437923OE 201367 201367H 160.914.104.370 LRS02704 201367R M0T37971 6035329.1 201367VAdd Your Number
