Specifications
Kilowatt | 0.95 kW |
Length (L.1) | 173.5 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | 9 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 19 mm |
Rotation | CW |
Spigot Diameter (A) | 66 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KUBOTA | Various Models |
Reference Information
MAV374010 MITM0TD2071 690.566.102.370 UD100061(MITSUBISHI)S 256690M M0TD2071AM M000TD2071AM 6035401.1 6C78259211 CST35401GS M000TD2071 M0TD2071 20437104OEAdd Your Number
