Specifications
Kilowatt | 1 kW |
Length (L.1) | 173 mm |
Mount Hole Center - Center (O.1) | 100 mm |
Mount Hole Center - Center (O.2) | 37 mm |
Mount Hole Center - Center (O.3) | 106 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
Mount Hole Diameter (C.3) | M10x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 15 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MAZDA | 2 1.3 | [ZJ46] | 10.2007-06.2015 |
MAZDA | 2 1.3 BiFuel | [ZJ-46] | 05.2011-11.2014 |
MAZDA | 2 1.3 MZR | [ZJ46] | 01.2010-06.2015 |
MAZDA | 2 1.3 MZR | [ZJ-VE] | 01.2010-06.2015 |
MAZDA | 2 1.5 | [ZY66] | 07.2007-06.2015 |
MAZDA | 2 1.5 | [ZY84] | 07.2007-06.2015 |
MAZDA | 2 1.5 | [ZY-VE] | 10.2007-06.2015 |
MAZDA | 2 1.5 MZR | [ZY05] | 06.2011-06.2015 |
MAZDA | 2 1.5 MZR | [ZY66] | 06.2011-06.2015 |
MAZDA | 3 1.6 | [Z6Y1] | 09.2013- |
MAZDA | 3 1.6 | [Z6Y3] | 09.2013- |
MAZDA | 3 1.6 MZR | [Z668] | 12.2008-09.2014 |
MAZDA | 3 1.6 MZR | [Z682] | 12.2008-09.2014 |
MAZDA | 3 1.6 MZR | [Z683] | 12.2008-09.2014 |
Reference Information
140.536.103.138 CGB-54246 ZJ38-18-400 0000986CN1623 UD100043(MITSUBISHI)S 9621 336108 115639 88213948 0986CN1623 PRSS441 140.536.103.780 MAV372660 STM1353 101469 LRS2574 M0T32771 140.536.103.265 8EA011611-951 STRS441 CST35266GS STR5228 M000T33971 25-4246 M000T32771AM MAV372660A J5213056 STR71327 6035266 DRS0483 000986025290 ZJ38 STM0124 M0T33971 S12MH0408A2 6035266.1 0000986CR1623 M000T32771 20437662BN 8EA738258-351 91-27-3548 LRS02574 12377 20437662OE 0986CR1623 S12MH0408 CS1469 MITM0T32771 101469M CST35266AS M0T32771AM MQS1469 30155N 140.536.103.130 986025290 140.536.103.370 63721469010Add Your Number
