Specifications
Kilowatt | 0.95 kW |
Length (L.1) | 173 mm |
Mount Hole Center - Center (O.1) | 77 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 20 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Micra 1.2 | [HR12DE] | 05.2010-09.2015 |
NISSAN | Micra 1.2 DIG-S | [HR12DDR] | 03.2011-09.2015 |
NISSAN | Micra 1.2 DIG-S | [HR12DR] | 03.2011-09.2015 |
NISSAN | Micra 1.2 LPG | [HR12DE] | 05.2010-09.2015 |
NISSAN | Note 1.2 | [HR12DE] | 06.2013- |
NISSAN | Note 1.2 DIG-S | [HR12DDR] | 06.2013- |
NISSAN | Note 1.2 DIG-S | [HR12DR] | 06.2013- |
NISSAN | Note 1.2 DIG-S | [HR12DR] | 12.2013- |
NISSAN | Note 1.2 LPG | [HR12DE] | 03.2015- |
Reference Information
S12MH0787 M0TD0971 M000TD0971 MITM0TD0971 23300-1HC1A 000986028080 160.586.092.130 23300-1HC1B M000T33671 23300-1HC0B 23300-1HC1C M000T37871 23300-1HC0D M000TD0971AM M0T37871 UD100059(MITSUBISHI)S M0TD0971AM 986028080 M000T37871ZE M0T37871AM M0T37871ZE CST35319GSAdd Your Number
