Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 188 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 8 qty |
| Pinion at Rest (B) | 4.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 66 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | Grand Vitara 2.0 | [J20A] | 10.2005-02.2015 |
Reference Information
STRF016 S12MH0336 20437183OE J5218027 LRS02382 6035381.1 115538 CST35381GS S12MH0336A2 9615 M000T21671 STR5291 25-4054 M000T21672 180.511.082.370 180.511.082.130 5035749 88214331 31100-65J10 101487M UD100037(MITSUBISHI)S CS1487 DRS0403 PRSF016 M0T21671 M0T21672 LRS2382 M000T21671AM M000T21672AM M0T21671AM M0T21672AM STR71340 STM1487Add Your Number
