Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 201 mm |
Mount Hole Center - Center (O.1) | 101 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 7 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MAZDA | MX-5 1.5 | [P5-VPR] | 06.2015- |
MAZDA | MX-5 1.5 | [P5X1] | 05.2018- |
MAZDA | MX-5 2.0 | [PE-VPR] | 05.2018- |
MAZDA | MX-5 2.0 | [PEX4] | 06.2015- |
MAZDA | MX-5 2.0 | [PEX6] | 06.2015- |
MAZDA | MX-5 2.0 | [PEXF] | 05.2018- |
MAZDA | MX-5 RF 1.5 | [P5X1] | 05.2018- |
MAZDA | MX-5 RF 1.5 | [P5Z1] | 08.2017- |
MAZDA | MX-5 RF 2.0 | [PEX6] | 12.2016- |
MAZDA | MX-5 RF 2.0 | [PEXF] | 05.2018- |
Reference Information
STM2568 UD100055(MITSUBISHI)S P59V 6035330.1 M000T89581 MITM0T89581 M0T89581 9809 20437033OE P59D-18-400 M000TD1271 P59D DRS1279 CST35330GS LRS04232 P59V-18-400 25-5394 140.551.112.370 LRS4232 M000T89581AM M0T89581AM M0TD1271 140.551.112.130Add Your Number
