Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 201 mm |
Mount Hole Center - Center (O.1) | 97 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MAZDA | 3 2.0 | [LF-VDS] | 05.2009-02.2012 |
MAZDA | 3 2.0 MZR | [LF17] | 06.2009- |
MAZDA | 3 2.0 MZR | [LF5H] | 06.2010- |
MAZDA | 3 2.0 MZR | [LF-DE] | 06.2009- |
MAZDA | 3 2.0 MZR-DiSi | [LF5H] | 06.2009- |
MAZDA | 3 2.0 MZR-DiSi | [LF5W] | 06.2009- |
MAZDA | 5 1.8 MZR | [L850] | 02.2013- |
MAZDA | 5 2.0 | [LFZB] | 01.2011- |
MAZDA | 6 1.8 MRZ | [L813] | 02.2008- |
MAZDA | 6 1.8 MRZ | [L813] | 08.2007- |
MAZDA | 6 2.0 MRZ | [LF17] | 02.2008- |
MAZDA | 6 2.0 MRZ | [LF17] | 08.2007- |
Reference Information
S-80591 M000T32871AM DS1836N M0T32871AM 20437353OE 17909N M000T32871 88213949 DRS0726N STM7271 25-4218 91-27-3543 LF4J-18-400 STR71076 M0T32871 STRE377 LRS2546 6035353.1 MITM0T32871 DS1836 DRS0726 PRSE377 140.550.112.130 116269 CST35353GS 140.550.112.370 STM1040 243-13101 3920 SG0845 UD100957(MITSUBISHI)S 19253N LRS02546Add Your Number
