Specifications
Amp | 35 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | 10.5 mm |
Diameter (D.2) | 12.5 mm |
Diameter (D.3) | 12.5 mm |
Grooves | 2 qty |
Groove Width (W.1) | 12 mm |
Length (L.1) | 192 mm |
Mount Inside Length or Pad Mount C-C (C) | 80.6 mm |
OEM Product | Yes |
Outside Diameter (O.D.1) | 49 mm |
Outside Diameter (O.D.2) | 79 mm |
Plug Code | PL_2003 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 42 mm |
Pulley Type | SOLID |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Canter 60 3.9 | [4D34-2AT4] | 08.1996- |
MITSUBISHI | Canter 75 3.9 | [4D34-2AT4] | 10.1997- |
Reference Information
12602N ME049281 CAL35605GS 156.501.045.139 230-30139 A003TRF388AM 156.501.045.138 CAL35605AS 0F042303061 20137506BN A3TR5288 UD100909(MITSUBISHI)A A3TR5288ZT A003TN5387AM DA2611 A003TRF388ZT DRA1501 20137506OE A3TN5188AM ALT5057 2035605 89214028 A003TN5387 A003TN5188 ME017614 A003TR5288 2035605.1 ME192607 A3TN5387 A3TRF388AM A3TN5188 2557 A3TRF388ZT A003TR5288ZT A003TRF388 113497 A3TRF388 ALM3497 F042303061 A003TN5188AM 210610 A3TN5387AMAdd Your Number
