Specifications
Kilowatt | 2.7 kW |
Length (L.1) | 297 mm |
Mount Hole Center - Center (O.1) | 128 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYSTER | Forklift | ||
YALE | Forklift |
Reference Information
CST40203AS DSN2117 254250 6040203.1 20432302OE UD810309(DENSO)S DENDSN2117 228000-7810 CST40203GS 336336 MAV422030A STN3985 228080-7810 1388721 6040203 20432302BN 254250D STR70314 MAV422030 640.515.103.050 19963N GSSN2117-NAdd Your Number
