Specifications
Kilowatt | 2 kW |
Length (L.1) | 249.5 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 88.6 mm |
Unit Type | DENSO |
Voltage | 12 V |
Wet Clutch | Yes |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | V60E | [4-236] | 01.1985- |
CATERPILLAR | V80E | [4-236] | 01.1985- |
HYSTER | H-100XL | [GM4.3] | 01.1996- |
HYSTER | H-110XL | [GM4.3] | 01.1996- |
HYSTER | H-130XL | [GM4.3] | 01.1996- |
HYSTER | H-80XL | [GM4.3] | 01.1996- |
YALE | Various Models |
Reference Information
1998329 140-10105 AEY2389 20432841BN 228080-5862 3001023 6040148 3T8191 DRS0575 STRS850 88213622 STN3172 8504304 655293 1998219 1107335 RNL5860ND 18198N 8063 2135890 LRS02389 1383240 1998293 640.509.102.260 MAV421480 128000-6870 640.509.102.265 254819 640.509.102.780 1109439 STRS804 113172 1998576 4525N 1109423 CST40148AS 228000-5860 228000-5861 1108493 7X1057 228000-5862 640.509.102.050 CGB-23034 S12DE0711A2 640.509.102.058 STR0C38 284074 1108443 335867 3112195 DENDSN2123 3136101 DSN2123 UD810315(DENSO)S STR6178 91-01-4248 25-4061 2200071-43 1109418 LRS2389Add Your Number
