Specifications
| Inside Diameter (I.D.1) | 12.3 mm |
| Length (L.1) | 45.5 mm |
| Length (L.2) | 14 mm |
| No./Splines | 8 qty |
| No./Teeth | 13 qty |
| Outside Diameter (O.D.1) | 49 mm |
| Outside Diameter (O.D.2) | 34.2 mm |
| Rotation | CW |
| Unit Type | VALEO |
Reference Information
05-110 060.001.118.000 SDV1042 69-74-65 36140-03301 UD101008SD 335578Video/Publications
488300 ESW20E18 S3158S CV2T11000AA CV2T11000AB CV2T11000ACAdd Your Number
