Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 210 mm |
Mount Hole Center - Center (O.1) | 97 mm |
Mount Hole Center - Center (O.2) | 14 mm |
Mount Hole Center - Center (O.3) | 100 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
Mount Hole Diameter (C.3) | M10x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 21.5 mm |
Rotation | CW |
Spigot Diameter (A) | 77 mm |
Unit Type | HYUNDAI / KIA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KIA | Seltos | 01.2019- |
Reference Information
UD101238S 000399707110 399707110 000399707109 36100-2M460 399707109Add Your Number
