Specifications
| Kilowatt | 3.5 kW |
| Length (L.1) | 276 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 21 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HATZ | Engine 1.7 | [2L41C] | |
| HATZ | Engine 1.7 | [2M41] | |
| HATZ | Engine 2.6 | [3L41C] | |
| HATZ | Engine 2.6 | [3M41] | |
| HATZ | Engine 2.6 | [3M43] | |
| HATZ | Engine 2.6 | [3M43-DPF] | |
| HATZ | Engine 2.6 | [3M43-EGR] | |
| HATZ | Engine 3.4 | [4L41C] | |
| HATZ | Engine 3.4 | [4L42C] | |
| HATZ | Engine 3.4 | [4M41] | |
| HATZ | Engine 3.4 | [4M42] | |
| HATZ | Engine 3.4 | [4M42-EGR] | |
| HATZ | Engine 3.4 | [4M43] | |
| HATZ | Engine 3.4 | [4M43-DFP] | |
| HATZ | Engine 3.4 | [4M43-EGR] |
Reference Information
731.006.112.310 AZE4286 72412088 AZE4184 255614M MAV236200 182-30493 CST21620GS 11.131.828 331691 MAHMS726 5.04791E+11 UD19575S 6021620.1 11.132.391 STI2457 IS1457 MS726 20419026OE 50648900 731.006.112.090 50479102Add Your Number
