Specifications
Kilowatt | 1.6 kW |
Length (L.1) | 194 mm |
Mount Hole Center - Center (O.1) | 139 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 25 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Vios 1.3 | 01.2008-12.2014 | |
TOYOTA | Vios 1.6 | 01.2008-12.2014 |
Reference Information
438000-1201 28100-0Y120 UD100999SAdd Your Number
