Specifications
Kilowatt | 1.9 kW |
Length (L.1) | 247 mm |
Mount Hole Center - Center (O.1) | 144 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 33 mm |
Rotation | CW |
Spigot Diameter (A) | 61 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LAND ROVER | Discovery 3.0 SCV6 4x4 | [306PS] | 09.2016- |
LAND ROVER | Range Rover 3.0 SCV6 4x4 | [306PS] | 04.2013-12.2019 |
LAND ROVER | Range Rover 3.0 SCV6 4x4 | [306PS] | 06.2015- |
LAND ROVER | Range Rover 3.0 SCV6 4x4 | [306PS] | 06.2015-12.2018 |
LAND ROVER | Range Rover 3.0 SCV6 4x4 | [306PS] | 10.2013- |
LAND ROVER | Range Rover 5.0 SCV8 4x4 | [508PS] | 01.2014-12.2018 |
LAND ROVER | Range Rover 5.0 SCV8 4x4 | [508PS] | 04.2013-12.2018 |
LAND ROVER | Range Rover 5.0 SCV8 4x4 | [508PS] | 06.2015- |
LAND ROVER | Range Rover 5.0 SCV8 4x4 | [508PS] | 08.2012- |
Reference Information
91-29-5910 UD18546S STN1712 DSN1416 6040470.1 450.549.122.050 FPLA-11001-AA 438000-1542 FPLA-11001-AB WOOSTR70542 DRS1222 438000-1541 438000-1540 438080-1542 LR061893 DENDSN1416 STM1446 MAV424700 255937D 450.549.122.260 20432074OE LR079918 CST40470GS SG2127 S6481S 30781NAdd Your Number
