Specifications
Kilowatt | 2.7 kW |
Length (L.1) | 320 mm |
Mount Hole Center - Center (O.1) | 146 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 24 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MASSEY FERGUSON | Mf 130 825 |
Reference Information
PRSS419 560.006.122.010 8831 560.006.122.011 331836 6010313.2 D11E85 CST10313AS 33535 20401313BN STR50786 UD19733S 20401313RC 1320502 CST10313RS CGB-23157 560.006.122.018 STRS419 254408 6010313Add Your Number
