Specifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 206 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 23 mm |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | 500X 1.0 | [55282151] | 06.2018- |
| FIAT | 500X 1.0 | [55282151] | 09.2018- |
| FIAT | 500X 1.3 | [55282328] | 09.2018- |
| FIAT | Tipo 1.0 | [55282151] | 11.2020- |
| JEEP | Renegade 1.0 T-GDi | [55282151] | 08.2018- |
| JEEP | Renegade 1.3 T-GDi | [55282328] | 08.2018- |
| JEEP | Renegade 1.3 T-GDi 4x4 | [55282328] | 08.2018- |
Reference Information
6010048.1 500.593.132.010 UD100731S 256556B 25-5517 1170417 500.593.132.280 50057673 51975679 0001170417 S0907S 20401840OE 221052 DRS1411 LRS04355 50057239 500.593.132.018 31138OS LRS4355 CST10048GSAdd Your Number
