Specifications
| Kilowatt | 0.7 kW |
| Length (L.1) | 185 mm |
| Mount Hole Center - Center (O.1) | 57 mm |
| Mount Hole Diameter (C.1) | 8.5 mm |
| Mount Hole Diameter (C.2) | 8.5 mm |
| No./Teeth | 15 qty |
| Pinion at Rest (B) | 38.5 mm |
| Rotation | ACW |
| Unit Type | SMALL MOTOR( Briggs, Kohler, UT etc) |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ARCTIC CAT | SBS 1000 | [480cc] | 01.2002-12.2002 |
| BRIGGS & STRATTON | Engine | [303447] | |
| CUB CADET | GT2521 | [(21HP)OHVV-Twin] | 01.2004-12.2004 |
| CUB CADET | LT2180 | [(18HP)OHVV-Twin] | 01.2003-12.2004 |
| JOHN DEERE | 1200 | [040000] | 01.2004-12.2019 |
| JOHN DEERE | 1200H | [040000] | 01.2004-12.2010 |
| JOHN DEERE | LT166 | [3037771162E1] | |
| JOHN DEERE | LT170 | ||
| JOHN DEERE | LTR166 | [3037771162E1] | |
| JOHN DEERE | SST16 | ||
| JOHN DEERE | SST18 | ||
| TORO | Greensmaster 3050 | 01.1995-12.2009 | |
| TORO | Greensmaster 3100 | 01.1990-12.2009 | |
| TORO | Greensmaster 3150 | 01.1990-12.2009 | |
| TORO | Grounds Pro 2000 | 01.1998-12.1999 | |
| TORO | Infield Pro 3040 | 01.2006-12.2009 | |
| TORO | Infield Pro 5040 | 01.2006-12.2009 | |
| TORO | Sand Pro 2020 | 01.1997-12.2009 | |
| TORO | Sand Pro 3020 | 01.1997-12.2006 | |
| TORO | Sand Pro 5000 | 01.1994-12.1997 | |
| TORO | Sand Pro 5020 | 01.1998-12.2006 | |
| TORO | Twister 1400 | 01.2002-12.2002 | |
| TORO | Twister 1600 | 01.2002-12.2008 |
Reference Information
STRE186 691564 8213 693469 SBS0028 PRSE186 71-35-5776 113539 6038142 MAV401420A 846451 91-35-1028 400.082.152.200 106-10304 5776 254504 Feb-07 400.082.152.208 844717 M143512 20415241BN 5776N STZ3539 STR88004 5072553 336118 185211 88213677 808106 843258 UD13658S 843259 CST38142AS S12BS0638A2Add Your Number
