Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 175 mm |
Mount Hole Center - Center (O.1) | 94 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 14 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | i20 1.0 T-GDi | [G3LC] | 01.2016- |
HYUNDAI | i20 1.4 | [G4LC] | 05.2015- |
HYUNDAI | i20 1.4 | [G4LC] | 11.2014- |
HYUNDAI | i20 Active 1.0 T-GDi | [G3LC] | 09.2015- |
HYUNDAI | i20 Active 1.4 | [G4LC] | 09.2015- |
Reference Information
6046123.1 36100-03851 8000748 150.939.112.038 LRS03909 88215175 MAV481230 36100-04900 CST46123GS 150.939.112.030 150.939.112.360 LRS3909 UD90557S 3738 20460321OE DRS1125 25-5072 256423D 8000798 3610003853Add Your Number
