Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 25 mm |
| Diameter (D.1) | M12x1.5 mm |
| Diameter (D.2) | 13 mm |
| Diameter (D.3) | 12.5 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 16 mm |
| Length (L.1) | 240 mm |
| Mount Inside Length or Pad Mount C-C (C) | 92 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 57 mm |
| Outside Diameter (O.D.2) | 94 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 65 mm |
| Pulley Type | SOLID |
| Unit Type | NIKKO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KOMATSU | D155AX-7 15.2 | [SAA6D140E] | 01.2012-12.2020 |
| KOMATSU | D155AX-8 15.2 | [SAA6D140E] | 01.2014-12.2020 |
| KOMATSU | D155AXi-8 15.2 | [SAA6D140E] | 01.2015-12.2020 |
| KOMATSU | D375A-5 23.15 | [SA6D170E] | 01.2001-12.2018 |
| KOMATSU | D375A-5 23.15 | [SAA6D170E] | 01.2001-12.2018 |
| KOMATSU | D375A-5D 23.15 | [SA6D170E] | 01.2001-12.2018 |
| KOMATSU | D375A-5E0 23.15 | [SAA6D170E] | 01.2005-12.2019 |
| KOMATSU | D375A-6 23.15 | [SAA6D170E] | 01.2010-12.2020 |
| KOMATSU | D475A-3 30.48 | [SDA12V140] | 01.1999-12.2008 |
| KOMATSU | D475A-5 30.48 | [SDA12V140E] | 01.2004-12.2008 |
| KOMATSU | D475A-5A 30.48 | [SDA12V140E] | 01.2004-12.2008 |
| KOMATSU | D475A-5E0 30.48 | [SAA12V140E] | 01.2007-12.2020 |
| KOMATSU | D475ASD-5E0 30.48 | [SAA12V140E] | 01.2007-12.2020 |
| KOMATSU | D61EX-23 6.7 | [SAA6D107E] | 01.2012-12.2020 |
| KOMATSU | D61EX-24 4.5 | [SAA4D107E] | 01.2015-12.2020 |
| KOMATSU | D61EX-24 6.7 | [SAA6D107E] | 01.2015-12.2020 |
| KOMATSU | D61EXi-23 6.7 | [SAA6D107E] | 01.2013-12.2020 |
| KOMATSU | D61EXi-24 4.5 | [SAA4D107E] | 01.2016-12.2020 |
| KOMATSU | D61EXi-24 6.7 | [SAA6D107E] | 01.2016-12.2020 |
| KOMATSU | D61PX-23 6.7 | [SAA6D107E] | 01.2012-12.2020 |
| KOMATSU | D61PX-24 4.5 | [SAA4D107E] | 01.2015-12.2020 |
| KOMATSU | D61PX-24 6.7 | [SAA6D107E] | 01.2015-12.2020 |
| KOMATSU | D61PXi-23 6.7 | [SAA6D107E] | 01.2013-12.2020 |
| KOMATSU | D61PXi-24 4.5 | [SAA4D107E] | 01.2016-12.2020 |
| KOMATSU | D61PXi-24 6.7 | [SAA6D107E] | 01.2016-12.2020 |
| KOMATSU | D65EX-15E0 8.3 | [SAA6D114E] | 01.2005-12.2010 |
| KOMATSU | D65EX-16 8.3 | [SAA6D114E] | 01.2010-12.2018 |
| KOMATSU | D65EX-17 8.3 | [SAA6D114E] | 01.2011-12.2020 |
| KOMATSU | D65EX-18 8.3 | [SAA6D114E] | 01.2015-12.2020 |
| KOMATSU | D65EXi-18 8.3 | [SAA6D114E] | 01.2015-12.2020 |
| KOMATSU | D65PX-15E0 8.3 | [SAA6D114E] | 01.2005-12.2010 |
| KOMATSU | D65PX-16 8.3 | [SAA6D114E] | 01.2011-12.2018 |
| KOMATSU | D65PX-17 8.3 | [SAA6D114] | 01.2011-12.2020 |
| KOMATSU | D65PX-18 8.3 | [SAA6D114E] | 01.2015-12.2020 |
| KOMATSU | D65PXi-18 8.3 | [SAA6D114E] | 01.2015-12.2020 |
| KOMATSU | D65WX-15E0 8.3 | [SAA6D114E] | 01.2004-12.2010 |
| KOMATSU | D65WX-16 8.3 | [SAA6D114E] | 01.2010-12.2011 |
| KOMATSU | D65WX-17 8.3 | [SAA6D114E] | 01.2010-12.2020 |
| KOMATSU | D65WX-18 8.3 | [SAA6D114E] | 01.2014-12.2020 |
| KOMATSU | D85EX-15E0 11.0 | [SAA6D125E] | 01.2006-12.2020 |
| KOMATSU | D85EX-18 11.0 | [SA6D125E] | 01.2015-12.2020 |
| KOMATSU | D85EXi-18 11.0 | [SA6D125E] | 01.2016-12.2020 |
| KOMATSU | D85PX-15E0 11.0 | [SAA6D125E] | 01.2006-12.2020 |
| KOMATSU | D85PX-18 11.0 | [SAA6D125E] | 01.2015-12.2020 |
| KOMATSU | D85PXi-18 11.0 | [SAA6D125E] | 01.2016-12.2020 |
| KOMATSU | GD555-5 6.7 | [SAA6D107E] | 01.2011-12.2020 |
| KOMATSU | GD655-3A 8.3 | [SAA6D114E] | 01.2006-12.2010 |
| KOMATSU | GD655-3C 8.3 | [SAA6D114E] | 01.2003-12.2011 |
| KOMATSU | GD655-3E0 8.3 | [SAA6D114E] | 01.2007-12.2011 |
| KOMATSU | GD655-5 6.7 | [SAA6D107E] | 01.2012-12.2018 |
| KOMATSU | GD655-6 6.7 | [SAA6D107E] | 01.2015-12.2020 |
| KOMATSU | GD675-3 8.3 | [SAA6D114E] | 01.2003-12.2011 |
| KOMATSU | GD675-3A 8.3 | [SAA6D114E] | 01.2007-12.2009 |
| KOMATSU | GD675-3E0 8.3 | [SAA6D114E] | 01.2007-12.2011 |
| KOMATSU | GD675-5 6.7 | [SAA6D107E] | 01.2010-12.2020 |
| KOMATSU | GD705-5 8.3 | [SAA6D114E] | 01.2014-12.2020 |
| KOMATSU | HB215C-3 4.5 | [SAA4D107E] | 01.2018-12.2020 |
| KOMATSU | HB365C-3 8.3 | [SAA6D114E] | 01.2016-12.2020 |
| KOMATSU | HD325-8 15.2 | [SAA6D140E] | 01.2016-12.2021 |
| KOMATSU | HD325-8E0 15.2 | [SAA6D140E] | 01.2016-12.2021 |
| KOMATSU | HD405-8 15.2 | [SAA6D140E] | 01.2016-12.2020 |
| KOMATSU | HD465-7E0 23.15 | [SAA6D170E] | 01.2006-12.2018 |
| KOMATSU | HD465-8 23.15 | [SAA6D170E] | 01.2017-12.2021 |
| KOMATSU | HD605-7E0 23.15 | [SAA6D170E] | 01.2006-12.2018 |
| KOMATSU | HD605-8 23.15 | [SAA6D170E] | 01.2017-12.2021 |
| KOMATSU | HD785-3 30.48 | [SA12V140] | 01.1988-12.1998 |
| KOMATSU | HD785-5 | [SA12V140] | 01.1996-12.2006 |
| KOMATSU | HD785-5 30.48 | [SA12V140] | 01.1999-12.2007 |
| KOMATSU | HD785-7 30.48 | [SAA12V140E] | 01.2007-12.2020 |
| KOMATSU | HM300-3 11.0 | [SAA6D125E] | 01.2012-12.2014 |
| KOMATSU | HM300-5 11.0 | [SAA6D125E] | 01.2015-12.2021 |
| KOMATSU | HM400-3 15.2 | [SAA6D140E] | 01.2012-12.2015 |
| KOMATSU | HM400-5 15.2 | [SAA6D140E] | 01.2015-12.2021 |
| KOMATSU | PC1100-6 23.1 | [SAA6D170E] | 01.1998-12.2002 |
| KOMATSU | PC1100C-6 23.1 | [SAA6D170E] | 01.1998-12.2002 |
| KOMATSU | PC1100SP-6 23.1 | [SAA6D170E] | 01.1998-12.2002 |
| KOMATSU | PC1250-11 23.1 | [SAA6D170E] | 01.2018-12.2020 |
| KOMATSU | PC1250-7 23.1 | [SAA6D170E] | 01.2002-12.2006 |
| KOMATSU | PC1250-8 23.1 | [SAA6D170E] | 01.2006-12.2020 |
| KOMATSU | PC1250C-11 23.1 | [SAA6D170E] | 01.2018-12.2020 |
| KOMATSU | PC1250C-7 23.1 | [SAA6D170E] | 01.2002-12.2006 |
| KOMATSU | PC1250C-8 23.1 | [SAA6D170E] | 01.2006-12.2020 |
| KOMATSU | PC1250SP-11 23.1 | [SAA6D170E] | 01.2018-12.2020 |
| KOMATSU | PC1250SP-7 23.1 | [SAA6D170E] | 01.2002-12.2006 |
| KOMATSU | PC1250SP-8 23.1 | [SAA6D170E] | 01.2006-12.2020 |
| KOMATSU | PC2000-11 30.48 | [SAA12V140E] | 01.2019-12.2020 |
| KOMATSU | PC2000-8 30.48 | [SAA12V140E] | 01.2007-12.2020 |
| KOMATSU | PC210-11 6.7 | [6D107E] | 01.2015-12.2021 |
| KOMATSU | PC210-11 6.7 | [SAA6D107E] | 01.2015-12.2021 |
| KOMATSU | PC210C-11 6.7 | [6D107E] | 01.2015-12.2021 |
| KOMATSU | PC210C-11 6.7 | [SAA6D107E] | 01.2015-12.2021 |
| KOMATSU | PC210Ci-11 6.7 | [SAA6D107E] | 01.2017-12.2021 |
| KOMATSU | PC240C-11 6.7 | [6D107E] | 01.2015-12.2021 |
| KOMATSU | PC240C-11 6.7 | [SAA6D107E] | 01.2015-12.2021 |
| KOMATSU | PC290-11 6.7 | [6D107E] | 01.2015-12.2021 |
| KOMATSU | PC290C-11 6.7 | [SAA6D107E] | 01.2015-12.2021 |
| KOMATSU | PC290C-11E0 6.7 | [SAA6D107E] | 01.2015-12.2021 |
| KOMATSU | PC290Ci-11 6.7 | [6D107E] | 01.2019-12.2021 |
| KOMATSU | PC290Ci-11 6.7 | [SAA6D107E] | 01.2019-12.2021 |
| KOMATSU | PC360C-11 8.3 | [6D114E] | 01.2015-12.2020 |
| KOMATSU | PC360C-11 8.3 | [SAA6D114E] | 01.2015-12.2020 |
| KOMATSU | PC360Ci-11 8.3 | [6D114E] | 01.2016-12.2020 |
| KOMATSU | PC360Ci-11 8.3 | [SAA6D114E] | 01.2016-12.2020 |
| KOMATSU | PC390C-11 8.3 | [SAA6D114E] | 01.2015-12.2020 |
| KOMATSU | PC390Ci-11 8.3 | [SAA6D114E] | 01.2017-12.2020 |
| KOMATSU | PC490C-11 11.0 | [SAA6D125E] | 01.2014-12.2021 |
| KOMATSU | PC490Ci-11 11.0 | [SAA6D125E] | 01.2016-12.2021 |
| KOMATSU | PC650C-11 15.2 | [SAA6D140E] | 01.2017-12.2021 |
| KOMATSU | WA200-1 6.5 | [6D105] | 01.1985-12.1987 |
| KOMATSU | WA200-6 4.5 | [SAA4D107E] | 01.2008-12.2020 |
| KOMATSU | WA200-7 4.5 | [SAA4D107E] | 01.2014-12.2020 |
| KOMATSU | WA200-8 4.5 | [SAA4D107E] | 01.2017-12.2021 |
| KOMATSU | WA200PZ-6 4.5 | [SAA4D107E] | 01.2008-12.2018 |
| KOMATSU | WA250-6 6.7 | [SAA6D107E] | 01.2008-12.2018 |
| KOMATSU | WA250PZ-6 6.7 | [SAA6D107E] | 01.2007-12.2017 |
| KOMATSU | WA270-7 6.7 | [SAA6D107E] | 01.2013-12.2020 |
| KOMATSU | WA270-8 6.7 | [6D107E] | 01.2016-12.2021 |
| KOMATSU | WA270-8 6.7 | [SAA6D107E] | 01.2016-12.2021 |
| KOMATSU | WA320-6 6.7 | [SAA6D107E] | 01.2008-12.2020 |
| KOMATSU | WA320-6N 6.7 | [SAA6D107E] | 01.2010-12.2014 |
| KOMATSU | WA320-7 6.7 | [SAA6D107E] | 01.2013-12.2020 |
| KOMATSU | WA320-8 6.7 | [6D107E] | 01.2016-12.2021 |
| KOMATSU | WA320-8 6.7 | [SAA6D107E] | 01.2016-12.2021 |
| KOMATSU | WA320PZ-6 6.7 | [SAA6D107E] | 01.2008-12.2010 |
| KOMATSU | WA380-5 8.3 | [SAA6D114E] | 01.2001-12.2008 |
| KOMATSU | WA380-6 6.7 | [SAA6D107E] | 01.2006-12.2010 |
| KOMATSU | WA380-7 6.7 | [SAA6D107E] | 01.2012-12.2020 |
| KOMATSU | WA380-8 6.7 | [SAA6D107E] | 01.2016-12.2021 |
| KOMATSU | WA400-5 8.3 | [SAA6D114E] | 01.2002-12.2007 |
| KOMATSU | WA430-5 11.0 | [SAA6D125E] | 01.2002-12.2005 |
| KOMATSU | WA430-6 8.3 | [SAA6D114E] | 01.2006-12.2020 |
| KOMATSU | WA470-5 11.0 | [SAA6D125E] | 01.2001-12.2006 |
| KOMATSU | WA470-8 11.0 | [6D125E] | 01.2015-12.2021 |
| KOMATSU | WA470-8 11.0 | [SAA6D125E] | 01.2015-12.2021 |
| KOMATSU | WA475-10 11.0 | [SAA6D125E] | 01.2020-12.2021 |
| KOMATSU | WA475-10EO 11.0 | [SAA6D125E] | 01.2020-12.2021 |
| KOMATSU | WA480-5 11.0 | [SAA6D125E] | 01.2002-12.2007 |
| KOMATSU | WA480-8 11.0 | [6D125E] | 01.2018-12.2021 |
| KOMATSU | WA480-8 11.0 | [SAA6D125E] | 01.2017-12.2021 |
| KOMATSU | WA500-7 15.2 | [6D140E] | 01.2012-12.2018 |
| KOMATSU | WA500-7 15.2 | [SAA6D140E] | 01.2012-12.2018 |
| KOMATSU | WA500-8 15.2 | [6D140E] | 01.2016-12.2021 |
| KOMATSU | WA500-8 15.2 | [SAA6D140E] | 01.2016-12.2021 |
| KOMATSU | WA600-6 23.15 | [SAA6D170E] | 01.2006-12.2020 |
| KOMATSU | WA700-3 23.15 | [SAA6D170E] | 01.1999-12.2010 |
| KOMATSU | WA800-2 30.48 | [SA12V140] | 01.1987-12.1997 |
| KOMATSU | WA800-3 30.48 | [SA12V140] | 01.2000-12.2007 |
| KOMATSU | WA800-3E0 30.48 | [SAA12V140E] | 01.2007-12.2020 |
| KOMATSU | WA900-3 30.48 | [SA12V140] | 01.2007-12.2020 |
| KOMATSU | WA900-3E0 30.48 | [SAA12V140E] | 01.2007-12.2020 |
| KOMATSU | WD600-6 23.15 | [SAA6D170E] | 01.2009-12.2017 |
| KOMATSU | WD900-3 30.48 | [SA12V140] | 01.2000-12.2020 |
Reference Information
0-35000-8390 600-825-9720 600-861-9121 553818RIN 115534 447211 600-861-9120 90-28-4037 UD91002A 600-821-9230 ALK9230 0-35000-8410 553818RI 600-825-9130 946.020.090.710 600-825-9230 600-825-9150 0-35000-8571 0-35000-8350 0-35000-8030 0-35000-8380 600-825-9710 600-825-9730 600-825-9310 600-825-9110 600-825-9330 4064077 285-35017 ALT35224 285-35076 600-821-9220 0-35000-8400 0-35000-8642 0-35000-8641 0-35000-8640 600-825-9120 946.020.090.200 0-35000-8360 0-35000-8040Add Your Number
