Specifications
Amp | 120 A |
Fitted with Bearing | Yes |
Length (L.1) | 157 mm |
Length (L.2) | 43 mm |
Outside Diameter (O.D.1) | 101.3 mm |
Outside Diameter (O.D.2) | 17 mm |
Poles | 12 qty |
Slip Ring to Suit | ASL9009 |
Thread Direction | Right |
Thread size & pitch (d.) | M14x1.5 mm |
Unit Type | DENSO |
Voltage | 12 V |
Reference Information
37340-3C170 AVN8416 UD49000AR 138416 KL47-18-W35 27330-50070 072.000.168.050 27330-20010 27330-50230 31101-PY3-J010M 021200-8020 27330-20070 021200-5030 021200-5130 021200-7450 27060-46300 UD46964AR RE51299 WRT67194 81113511 27330-64520 RES6723 RES6626 021200-7090 021200-7641 021200-8010 021200-4890 27330-46090 28-8204Video/Publications
1210004390 1012117410 1002116360 1012117892 1012117891 1022113290 1210004550 1012117370 1012117090 1012117091 A6515S 1022110650 A9311S 1002116310 1022110691 1210004160 1002116030 1002116031 1012117860 1012117340 1012117780 1002116110 1012117220 1012117020 1210004520 1210004440 1210004320 A6126 1012117060 A6388S 1210004161 1002116190 A6659S A6526S A6053 1022110800 1022110520 1022110840 1002116420 1012119931 1012117630 1012117872 1012117870 1012117551 1012117871 1012117230 1210004331 1012117070 1210004010 102211-0512 1022110830 1022110710 1022110870 1022110670 1012117320 1012117761 1012117000 1012117440 1002116170 1002116050 1012117160 1002116051 A6512S A6029 A6035 373004A310 1022110980 1022110860 1022110981Add Your Number
