Specifications
Amp | 65 A |
Bottom Mounting Foot Width (B) | 11 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 8 mm |
Diameter (D.3) | 8 mm |
Grooves | 2 qty |
Groove Width (W.1) | 9 mm |
Length (L.1) | 178 mm |
Mount Inside Length or Pad Mount C-C (C) | 81 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 51 mm |
Outside Diameter (O.D.2) | 75 mm |
Plug Code | PL_9105 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 34 mm |
Pulley Type | SOLID |
Unit Type | ISKRA / LETRIKA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CASE | CX 70 4.0 | [G4.0] | 01.1997-12.2000 |
CASE | CX 70 4.0 | [G4.0T] | 01.1997-12.2000 |
CASE | MC 100 4.0 | [4TWG] | |
CASE | MC 80 4.0 | [4T] | |
MCCORMICK | CX 100 4.4 | [1104D-44TA] | |
MCCORMICK | CX 70 4.2 | [104-42] | |
MCCORMICK | CX 80 4.0 | [1004-4THR] | |
MCCORMICK | CX 90 4.0 | [G4.0] | |
MCCORMICK | CX 90 4.0 | [G4.0T] | |
MCCORMICK | MC 90 4.0 | [4WTG] |
Reference Information
645.058.065.090 90-23-6513 72735402 MAHMG403 MG403 PRAF756 2021181.1 A188590A1 11.201.877 UD03607A 20119181OE 710366A1 645.058.065.311 AAK3313 ALT79204 73327984 388189A1 CAL21181GS 90-23-6513N IA0877 89216301 A9385S ALTF756Add Your Number
