Specifications
Amp | 70 A |
Bottom Mounting Foot Width (B) | 13.5 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | M10x1.25 mm |
Diameter (D.3) | 10 mm |
Length (L.1) | 164 mm |
Mount Inside Length or Pad Mount C-C (C) | 66 mm |
OEM Product | No |
Plug Code | PL_2004 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 43.5 mm |
Pulley Type | SOLID |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Probe 2.2 | [LC22] | 08.1988-07.1993 |
MAZDA | 626 1.8 | [F8] | 01.1988-03.1992 |
MAZDA | 626 1.8 | [F8] | 09.1987-08.1991 |
MAZDA | 626 1.8 | [F8] | 11.1987-05.1992 |
MAZDA | 626 2.0 | [FE] | 09.1987-10.1990 |
MAZDA | 626 2.0 12V | [FE] | 09.1987-01.1990 |
MAZDA | 626 2.0 12V | [FE] | 09.1987-05.1992 |
MAZDA | 626 2.0 12V | [FE] | 09.1987-12.1988 |
MAZDA | 626 2.0 12V | [FE] | 09.1987-12.1992 |
MAZDA | 626 2.0 12V | [FE] | 11.1987-05.1992 |
MAZDA | 626 2.0 16V | [FE] | 01.1988-03.1992 |
MAZDA | 626 2.0 16V | [FE] | 06.1987-08.1989 |
MAZDA | 626 2.0 16V | [FE] | 11.1987-05.1992 |
MAZDA | 626 2.0 16V | [FE] | 11.1987-10.1990 |
MAZDA | 626 2.0 16V | [FE] | 12.1987-10.1990 |
MAZDA | 626 2.0 4x4 | [FEFL] | 08.1989-07.1991 |
MAZDA | 626 2.0 i 16V | [FECM] | 10.1988-09.1997 |
MAZDA | 626 2.2 12V 4WD | [F2] | 01.1990-05.1992 |
MAZDA | 626 2.2 12V 4WD | [F2] | 05.1991-11.1992 |
MAZDA | 626 2.2 12V 4WD | [F2L1] | 05.1991-11.1992 |
Reference Information
F290-18-300 110664 ALT371150A 89213764 A2T45877 0986036471 ALT31214 986036471 145.508.070.605 A002T20191 A2T05892 445624 A2T05893 A002T07577 F28518300B 145.508.070.130 JA575IR 145.508.070.375 CGB-81508 F88118300 A002T05892ZC F29018300 13196N F8B1-18-300 A2T20191ZC A2T05892ZC PRAW100 LRA0790 F28518300 A005T10377 20137511BN ALTW100 A2T19991 2035115 F285-18-300C 66021301 A004A2F05892 210158 F22518300 F202-18-300 A2T40571 F290-18-300B F8B1-18-300C TA000B16701 F8B1-18-300A F8B1-18-300B F8B118300EX A002T45877 F8B1-18-300G 145.508.070.785 AG0360 3110085021 28-1508 LRA00790 56237 A2T07577 F29018300A A002T05893 A002T05892 A2T20191 A2T19991A ALM0575 UD53089A A002T20191ZC A002T05893ZC LRA790 JE0718300 145.508.070.415 A2T05893ZC A5T10377 8EL726359-001 F26218300 90-27-3036N 13196 A002T05892B J5113018 A002T19991 F28518300C A4A2F05892 F88118300A F28518300E A2T05892B JE018300 DRA3098 9174 E92Z-10346-B 9.44357E+11 FEB1-18-300B CGB-13098 E92Z-10346-A 90-27-3036 CAL35115AS 40575RI MRA93501Add Your Number
