Specifications
Amp | 220 A |
Bottom Mounting Foot Width (B) | 21 mm |
Diameter (D.1) | 11.5 mm |
Diameter (D.2) | 11.5 mm |
Diameter (D.3) | M10x1.5 mm |
Diameter (D.4) | M10x1.5 mm |
Grooves | 6 qty |
Length (L.1) | 180 mm |
Mount Inside Length or Pad Mount C-C (C) | 45 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 54 mm |
Plug Code | PL_3402 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 43 mm |
Pulley Type | CLUTCH |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Mondeo 1.5 TDCi | [UGCC] | 03.2015- |
FORD | Mondeo 1.5 TDCi | [XUCA] | 03.2015- |
FORD | Mondeo 1.6 TDCi | [NGCA] | 09.2014- |
FORD | Mondeo 1.6 TDCi | [U3CA] | 09.2014- |
Reference Information
DS7T-10300-MC 9084 WOOALT14677 A12VA1054AS 28-7648 595.908.220.004 595.908.220.500 CAL15074GS VAL439952 439952 20179470OE UD101284A DS7T-10300-MA DS7T-10300-MB 55151279 1865468 209633 NFG23S071 FG23S071 LRA4039 AEG1342 DRA1695 LRA04039 2015074.1 89216511 21015-OS 554686RIV 440709Add Your Number
