Associated Numbers
11040775 EuroTec 120521092 PSH 2280009590 Denso 2280009650 2280009651 254083 Elstock 31200PLCT51 Honda 31200PLRA52 322057092 DRI 6040358 Sando 910579 EDR AEY2411 Auto Electro DDVDI DRS0579 Remy DSDEV LRS02411 Lucas NSM1550 Napa (UK) RNL2280009590 RNL 120523092 2280009652 snj285Specifications
| Kilowatt | 1 kW |
| Length (L.1) | 205 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 33 mm |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | CIVIC 1.5 | D15Y4 | |
| HONDA | CIVIC 1.5 | D15Y6 | |
| HONDA | CIVIC 1.7 | D17A | |
| HONDA | CIVIC 1.7 | D17A2 |
Reference Information
2280009650 2280009651
