Associated Numbers
102211-2710 2706022120
1022112940 2706022220
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 22.5 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.4) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 168 mm |
| Mount Inside Length or Pad Mount C-C (C) | 40.3 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_4000 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 57.25 mm |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.4 | [4ZZ-FE] | 03.2007-09.2012 |
| TOYOTA | Avensis 1.6 VVT-i | [3ZZ-FE] | 04.2003-11.2008 |
| TOYOTA | Avensis 1.8 | [1ZZ-FE] | 04.2003-11.2008 |
| TOYOTA | Corolla 1.4 VVT-i | [4ZZ-FE] | 11.2006-11.2013 |
| TOYOTA | Corolla 1.6 VVT-i | [3ZZ-FE] | 01.2002-08.2007 |
| TOYOTA | Corolla 1.8 | [2ZR-FE] | 10.2006-07.2014 |
| TOYOTA | Corolla Verso 1.6 | [3ZZ-FE] | 04.2004-03.2009 |
| TOYOTA | Corolla Verso 1.8 | [1ZZ-FE] | 04.2004-03.2009 |
