Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 12.6 mm |
Inside Diameter (I.D.1) | 25.2 mm |
L.B+ | 14.7 mm |
Length (L.1) | 67.9 mm |
Outside Diameter (O.D.1) | 53.8 mm |
Outside Diameter (O.D.2) | 47.8 mm |
Unit Type | VALEO |
Voltage | 12 V |
Reference Information
CSO15101 4.6007.1 UD00368SS SSV5106 E7475 UD02994SS VAL594348 AME0570 CED5120 594348 UD02714SS SND12928 66-9440 9.40113E+11 20379101 4.6194.9 SOL0031 SS3021 227171 ZM2494 81015218 235106 054.000.109 SSO15101Video/Publications
4.6007.1 SSV5106 UD02994SS VAL594348 AME0570 594348 D7E16 66-9440 TS10E1 4.6194.9 227171 235106 438129 S3005 D7E5 054.000.109 D7E2 TS8E2 CSO15101 UD00368SS 940113050570 S3032 E7475 CED5120 D7E23 D7E25 D7E47 UD02714SS SND12928 438093 20379101 SS3021 ZM2494 81015218 SSO15101Add Your Number
