Specifications
Kilowatt | 2 kW |
Length (L.1) | 202 mm |
Mount Hole Center - Center (O.1) | 122 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 13 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Auris 1.4 D-4D | [1ND-TV] | 01.2012- |
TOYOTA | Corolla 1.4 D-4D | [1ND-TV] | 01.2013- |
TOYOTA | Yaris 1.4 D-4D | [1ND-TV] | 01.2014- |
Reference Information
190.926.092.050 20432724OE 88215038 256329D 428080-9061 AEY2511 CST40427GS STR6778 3350 428000-9061 428000-9060 DRS0924 DSN1234 6040427.1 UD808766(DENSO)S DENDSN1234 116472 LRS04114 STRJ087 28100-0N110 25-5277 LRS4114Add Your Number
