Specifications
Kilowatt | 3 kW |
Length (L.1) | 340 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 19 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | E70 | ||
RENAULT | N70 | ||
RENAULT | P70 | ||
RENAULT | Super 6 | ||
RENAULT | Super 6D |
Reference Information
855196100 STRE473 1358031 DEM1345 570.004.093.010 EJD312BR14 8461 PRSE473 UD19708SAdd Your Number
