Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 229 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | M12x1.75 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 27.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Reference Information
CGB-52265 PRSS925 101074 943253150010 220476 MAV121590 AEU1074 LRS01386 944280183400 STR50057 S1028B 17778N 20401951BN 0001108221 0001108220 EAA-121264 8EA737479-001 MAV172100 25-2265 8EA012527-261 6010159.0 0986018340 UD807223(BOSCH)S STRS925 88212525 078911023D LRS1386 22.1074 8212525 0001108175 0001108174 0986018347 CS1074 3017 458211 MSR5350 42018340 AI-80146 943210741010 8018340 111769 200.512.092.216 078911023DX CST10159AS 116344 11859 200.512.092.210 200.512.092.010 DRS8340 063721074010Add Your Number
