Specifications
Amp | 150 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.25 mm |
Diameter (D.4) | M10x1.25 mm |
Grooves | 6 qty |
Length (L.1) | 166 mm |
Mount Inside Length or Pad Mount C-C (C) | 60.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 55 mm |
Plug Code | PL_2306 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 31 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LEXUS | NX 200t 2.0 | [8AR-FTS] | 07.2014- |
LEXUS | NX 300 2.0 | [8AR-FTS] | 09.2017- |
LEXUS | RX 200t 2.0 | [8AR-FTS] | 10.2015-12.2017 |
LEXUS | RX 300 2.0 | [8AR-FTS] | 12.2017- |
Reference Information
28-8506 LRA04397 UD19684A 104211-8861 27060-36101 104211-8860 27060-36100 40623 ALN3661 LRA4397 90-29-5882Add Your Number
