Associated Numbers
03H903023C VW 03H903023CX 12090548 EuroTec 2113731802 DRI 2610416A Valeo 285932 Elstock 305593180 PSH 439735 440325 610416 9090616 Friesen 9090616F 930805 EDR DRA0805 Remy FG18T017 FG18T070 show FGN18T070 LRA03320 Lucas LRA3320 WAI Old 11805N Armature G Roy 11805 Audi Volkswagen 03H-903-023C 03H-903-023CX Autoelectro AEK3320 Casco CAL15432GS A/S Denmark EGI A-11805 Lester Electrical Europe Mondial 60-275-240 Our Part Number # PIC 220-5724 Power Select Powerite Automotive Raw Road Warrior New Remanufactured Tech Wood Auto Supplies VAL439735Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 188 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Plug Code | PL_2306 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VW | Touareg 3.6 VR6 |
