Associated Numbers
2015297 20179792OE 23892N 2542955 2542955A 2542955B 2542955E 2606293A 2661540802 28-5509 301875RIR 301875RIV 555.560.090.004 89213722 9090538 9213722 A2661540802 A2661541002 A2661541202 AEC1875 CA1875IR CAL15297GS DRA0102 LRA02892 SB235 SG9B068 SG9B079 SG9B121 UD11341A VALSG9B121 0986080500 Bosch ruil 115418 Cargo 12090311 EuroTec 225154902 DRI 2261541202 Mercedes-Benz Valeo show 2661541202 266154120280 285509 Elstock 32080500 Herth Buss 437537 439544 4795 CEVAM 555560090 PSH 606293 6333SP Spidan 747076 8EL738211441 Hella 9090538F Friesen 930102 EDR 944390905380 Magneti Marelli A2261541202 A266154120280 ALT00260sa Electrolog HC Remy HCA1875IR L82290 ATL Lucas MRA90538 OAN12264 Optimum aam-S5042Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 194 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 49 mm |
| Pad mount thickness (E.1) | 74 mm |
| Pad mount thickness (E.2) | 142 mm |
| Plug Code | PL_2300 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 40 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SKODA | Superb 3.6 FSi 4x4 | [CDVA] | 11.2008-05.2015 |
| SKODA | Superb 3.6 V6 4x4 | [CDVA] | 10.2009-05.2015 |
| VW | California 2.0 TDi | [CAAA] | 01.2009- |
| VW | California 2.0 TDi | [CAAB] | 01.2009- |
| VW | California 2.0 TDi | [CAAC] | 01.2009- |
| VW | California 2.0 TDi | [CAAE] | 01.2009- |
| VW | California 2.0 TDi | [CCHA] | 01.2009- |
| VW | California 2.0 TDi | [CCHB] | 01.2009- |
| VW | California 2.0 TDi | [CFCA] | 01.2009- |
| VW | Caravelle 2.0 TDi | [CAAA] | 01.2009- |
| VW | Caravelle 2.0 TDi | [CAAB] | 01.2015- |
| VW | Caravelle 2.0 TDi | [CAAC] | 01.2015- |
| VW | Caravelle 2.0 TDi | [CAAE] | 01.2009- |
| VW | Caravelle 2.0 TDi | [CCHA] | 01.2009- |
| VW | Caravelle 2.0 TDi | [CCHB] | 01.2009- |
| VW | Caravelle 2.0 TDi | [CFCA] | 01.2009- |
| VW | Caravelle 2.0 TDi | [CHCB] | 01.2009- |
| VW | Caravelle 2.0 TDi 4-Motion | [CAAC] | 01.2015- |
| VW | Crafter 2.0 TDi | [CKTB] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKTC] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKUB] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKUC] | 01.2011- |
| VW | Crafter 2.0 TDi | [CS..] | 01.2011- |
| VW | Crafter 2.0 TDi 4-Motion | [CKUB] | 01.2011- |
| VW | Crafter 2.0 TDi 4-Motion | [CSNA] | 01.2011- |
| VW | Multivan 2.0 TDi | [CAA.] | 01.2009- |
| VW | Multivan 2.0 TDi | [CAAB] | 01.2015- |
| VW | Multivan 2.0 TDi | [CAAC] | 01.2015- |
| VW | Multivan 2.0 TDi | [CCH.] | 01.2009- |
| VW | Multivan 2.0 TDi | [CFCA] | 01.2009- |
| VW | Multivan 2.0 TDi 4-Motion | [CAA.] | 01.2009- |
| VW | Multivan 2.0 TDi 4-Motion | [CAAC] | 01.2015- |
| VW | Multivan 2.0 TDi 4-Motion | [CCH.] | 01.2009- |
| VW | Multivan 2.0 TDi 4-Motion | [CFCA] | 01.2009- |
| VW | Passat 3.2 FSi | [AXZ] | 01.2007- |
| VW | Passat 3.6 FSi | [BLV] | 01.2005- |
| VW | Passat 3.6 FSi | [BWS] | 01.2007- |
| VW | Passat CC 3.6 FSi 4-Motion | [BLV] | 01.2008-12.2012 |
| VW | Passat CC 3.6 FSi 4-Motion | [CNNA] | 01.2008-12.2012 |
| VW | Transporter 2.0 TDi | [CAA.] | 01.2009- |
| VW | Transporter 2.0 TDi | [CAAA] | 01.2015- |
| VW | Transporter 2.0 TDi | [CAAB] | 01.2015- |
| VW | Transporter 2.0 TDi | [CAAC] | 01.2015- |
| VW | Transporter 2.0 TDi | [CCH.] | 01.2009- |
| VW | Transporter 2.0 TDi | [CFCA] | 01.2009- |
| VW | Transporter 2.0 TDi 4-Motion | [CAA.] | 01.2009- |
| VW | Transporter 2.0 TDi 4-Motion | [CAAC] | 01.2015- |
| VW | Transporter 2.0 TDi 4-Motion | [CCH.] | 01.2009- |
| VW | Transporter 2.0 TDi 4-Motion | [CFCA] | 01.2009- |
Reference Information
301875RIR 2015297 89213722 301875RIV VALSG9B121 28-5509 9090538 DRA0102 LRA02892 A2661541202 A2661541002 ALT172970 20179792OE UD11341A 2661540802 SB235 SG9B068 555.560.090.004 SG9B121 AEC1875 A3319 2542955 A2661540802 23892N CAL15297GS LRA2892 2542955E 2542955A 2542955B AX ALTL795 210552 SG9B079 2606293A 9213722 CA1875IR 1405Video/Publications
2015297 20179792OE 210552 23892N 2542955 2542955A 2542955B 2542955E 2606293A 2661540802 28-5509 301875RIR 301875RIV 555.560.090.004 89213722 9090538 A2661540802 A2661541002 A2661541202 AEC1875 ALT172970 ALTL795 AX 1405 CA1875IR CAL15297GS DRA0102 LRA02892 LRA2892 SB235 SG9B068 SG9B079 SG9B121 UD11341A VALSG9B121Add Your Number
