Specifications
| Kilowatt | 4.8 kW |
| Length (L.1) | 342 mm |
| Mount Hole Center - Center (O.1) | 89 mm |
| Mount Hole Center - Center (O.2) | 89 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 28.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | 2384D | ||
| CATERPILLAR | 2484D | ||
| CATERPILLAR | 312E | ||
| CATERPILLAR | 312EL | ||
| CATERPILLAR | 312F | ||
| CATERPILLAR | 313FL | ||
| CATERPILLAR | 314ECR | ||
| CATERPILLAR | 314ELCR | ||
| CATERPILLAR | 314FCR | ||
| CATERPILLAR | 315F | ||
| CATERPILLAR | 316EL | ||
| CATERPILLAR | 316FL | ||
| CATERPILLAR | 318FL | ||
| CATERPILLAR | 320 | ||
| CATERPILLAR | 320-07GC | ||
| CATERPILLAR | 320FL | ||
| CATERPILLAR | 320GC | ||
| CATERPILLAR | 323F | ||
| CATERPILLAR | 323FLN | ||
| CATERPILLAR | 323FOEM | ||
| CATERPILLAR | 323FSA | ||
| CATERPILLAR | 325F | ||
| CATERPILLAR | 325FLCR | ||
| CATERPILLAR | 559D | ||
| CATERPILLAR | 579D | ||
| CATERPILLAR | AP500F | ||
| CATERPILLAR | AP555F | ||
| CATERPILLAR | AP600F | ||
| CATERPILLAR | AP655F | ||
| CATERPILLAR | CP-54B | ||
| CATERPILLAR | CP-56B | ||
| CATERPILLAR | CP-68B | ||
| CATERPILLAR | CS-54B | ||
| CATERPILLAR | CS-56B | ||
| CATERPILLAR | CS-64B | ||
| CATERPILLAR | CS-68B | ||
| CATERPILLAR | D6K2 | ||
| CATERPILLAR | D6K2LGP | ||
| CATERPILLAR | D6K2XL | ||
| CATERPILLAR | Engine | [C4.4] | |
| CATERPILLAR | PL61 |
Reference Information
432-1691 428000-2851 438000-2850 S6448S UD19273SAdd Your Number
