Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 185 mm |
Mount Hole Center - Center (O.1) | 97 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 21.5 mm |
Rotation | CW |
Spigot Diameter (A) | 77 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Elantra 1.6 | [G4FG] | 02.2016- |
HYUNDAI | Tucson 1.6 T-GDi | [G4FJ] | 06.2015-09.2020 |
HYUNDAI | Veloster 1.6 GDi | [G4FD] | 03.2011-12.2017 |
HYUNDAI | Veloster 1.6 MPi | [G4FC] | 04.2011-12.2017 |
HYUNDAI | Veloster 1.6 T-GDi | [G4FJ] | 10.2012-12.2017 |
Reference Information
25-5300 LRS04137 88215053 36100-2B510 STA5884 91-20-3590 UD19704S S3232S 1205004 LRS4137Add Your Number
