Associated Numbers
057911023J VW
057911023JX VW
255296 Elstock
300938112 PSH
311421112 DRI
3371 CEVAM
4380000111 Denso
95860411200 Porsche
958604112X VW
LRS04133 Lucas
4380000112 4380000113
Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 252 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Center - Center (O.2) | 108 mm |
Mount Hole Center - Center (O.3) | 20 mm |
Mount Hole Diameter (D.1) | 11.5 mm |
Mount Hole Diameter (D.2) | M10x1.5 mm |
Mount Hole Diameter (D.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 26 mm |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | |||
SKODA | |||
VW |
